5. FINAL STEP

5.1. Check-list

Before commissioning the gate, check if all cables and wires are correctly fixed, and proceed with the
various electrical tests: opening and closing of the obstacles, proper operation of the detection photocells,
function and/or orientation pictograms (options), readers (client's supply), etc.
Check if all wires are firmly connected to their respective terminal blocks.
Check if the yellow LED of all cells is on in stand-by mode, and make sure the corresponding LEDs are also
on on the PLC fascia and go off whenever the cells are occulted. If needed, adjust the cells referring to
paragraph [8.2. Detection photocell adjustment].
For each mechanical group, check if the obstacle is properly locked after an opening movement (passage-
way closed), with motor stopped, and if it is fully integrated into the housing after a closing movement
(passage-way free), also with motor stopped. If not, refer to paragraph [8.1. Limit switch cam adjustment].
Check the constance (tolerance +/-0.5mm) of the slot width on the upper part of the gate and which
accommodates the obstacle in open position (passage-way free). The synthetic shutter closes this slot for
safety purposes when the obstacle is out of the housing. In the case of a PNG380 without fixed obstacle, the
slot is not present.
Check (if this option is programmed in the variable speed controller) if the obstacle opens properly in case
the equipment is powered off, i.e., proper operation of the anti-panic device.
Check if all screws and nuts have been tightened firmly.
Check if you did not forget any tool remaining inside the gate.
Remove any foreign body from the inside of the gate (scraps, etc.), and clean.
In the case of a PNG381 or PNG382, replace and lock the lateral extension door(s) (10:7) and (10:8).
In the case of a PNG381 or PNG382, close and lock the hood(s) (10:5) and (10:6).
Close and lock the lateral, hinged polyester doors (10:1) to (10:4).
⇒
The gate is now operational. Although all adjustments have been carried out in factory, a final regulation
may be required after the transport or mounting procedure. In this case, see chapter [8. Mechanical
adjustments and interventions]. All adjustments are of the electronic type. Please contact Automatic
Systems for more details.
