1.6 Main components

17
18
power supply
230 V 50 Hz
120 V 60 Hz
21
21
22
23
20
water drain
3/4" GAS F
Cabinet water circuit
Ref. Description
1 Water inlet filter
2 Pressure reducer
3 NC fill solenoid valve
4 Low pressure gauge
5
Motor
6
Pump
7
High pressure gauge
8 High pressure sensor
9 Temperature-controlled safety valve
10 High pressure sensor
11 Temperature sensor
12 Overflow valve
13 Drain solenoid valve
14 Bypass solenoid valve
15 NC fill solenoid valve
16
NO return solenoid valve
17
Fuse kit
18 pGDx display
19 Controller
20 Expansion card
21 Transformer
22 SSR
23 Cooling fan
19
1
3
11
5
7 8
Fig. 1.d
8
7
Ref. Description
1 metal support / wall bracket
2 side plastic cover
3 centre plastic cover
4 pressurised water manifold
5 nozzle
6 power LED
7 terminal block for blower power supply
8
fan
9
water inlet
3/4" GAS F
2
4
16
2
15
and return
M16x1.5
15
male
1
16
14
10
12 13
9
6
input / output water
Single-blower: M16 x 1.5 male
Double blower: M16 x 1.5 female
1
6 5 4 3
Fig. 1.e
