Supervisor Connection; List Of Modbus Parameters - Carel humiFog direct UA040DD101 User Manual

ENG
pGD1
The pGD1 page opens a keyboard for advanced configuration of the unit.
Alarms
Display active alarms and alarm log.
Unit
Display the values of the digital and analogue inputs and outputs on the
unit.
Log
The Log page is used to generate graphs of the selected variables,
based on the logged data, and export these in .csv format.
Variables
Displays all of the variables logged by the unit.
The variables are available grouped into predefined categories, all of
which are active by default.
Upgrade
Page reserved for remote software upgrades.
Clock
Display and set the unit clock

8.3 List of Modbus parameters

Type Section
Discrete inputs Unit status
Alarms
Input registers Unit status
Inputs
"humiFog direct" +0300073EN rel. 1.2 - 02.05.2019
Address Parameter
1 Unit on/off
2 Circuit breaker intervention
3 High pressure switch intervention
4 High pressure
5 Low pressure
6 High pressure on bypass
7 High pressure on bypass
8 High temperature on bypass
9 High temperature on bypass
10 Low pressure on bypass
11 Zone drain valves error
12 Expansion offline
13 Warning high temperature on bypass
14 Retain memory error
15 Retain memory writes error
16 Main probe 1 error
17 Limit probe 1 error
18 Main probe 2 error
19 Limit probe 2 error
20 Low pressure trasducer error
21 Bypass temperature probe error
22 High pressure transducer error
23 Missing model
24 Water treatment system alarm
25 - 32 Wireless probe offline 1 - 8
33 Main probe 1 from wireless error
34 Limit probe 1 from wireless error
35 Main probe 2 from wireless error
36 Limit probe 2 from wireless error
37 - 40 Unit 1 - 4 alarm
41 Change oil
42 Maintenance
43 Maintenance required
1 Unit status
0: OFF BY KEYB
1: OFF BY DIN
2: OFF BY SV
3: OFF BY SCHED 8: FILL
4: STARTUP
2 Request zone 1
4 Request zone 2
6 Production zone 1
8 Production zone 2
10 Water consumption 1
12 Water consumption 2
14 Main probe 1
16 Main probe 2
18 Limit probe 1
20 Limit probe 2
22 Pressure on bypass
24 Pressure on main line
Important: to avoid unwanted modifications, some of the main operating
and unit parameters can only be set on the web server when the unit is
off (off from keypad, settable on the web server).

8.2 Supervisor connection

The supervisor connection uses the serial or Ethernet port (as described
in paragraph 4.6). The default communication settings are Modbus on
serial port and BACnet on Ethernet port.
If connecting to the serial port, enable the chosen protocol (Modbus or
BACnet) on the screens. For Modbus protocol only, set the baud rate/
stop bits/parity. The default values (baud rate: 19000 / 2 stop bits / no
parity) should work in almost all cases, unless otherwise specified by the
supervisor network installer.
If connecting via Ethernet, follow the procedure (described in paragraph
8.1.1) to look up the unit's IP address, then establish whether the
communication protocol will be BACnet and/or Modbus.
Important: if using BACnet protocol on a serial port, it cannot be used on
the Ethernet port (and vice-versa). The Modbus protocol can on the other
hand be used at the same time on both ports.
For all other information, see the manual for the supervisor used and/or
contact the supervisor network manager.
Variable
UnitOn
Al_CircBreaker.Active
Al_HiPSwitch.Active
Al_HiP.Active
Al_LoP.Active
Al_HiPByPassBlk.Active
Al_HiPByPass.Active
Al_HiTByPassBlk.Active
Al_HiTByPass.Active
Al_LoPByPass.Active
Al_Drain.Active
Al_ExpOffline.Active
Wr_HiTByPass.Active
Al_Retain.Active
Al_RetainWrite.Active
Al_MainPrb_1.Active
Al_LimPrb_1.Active
Al_MainPrb_2.Active
Al_LimPrb_2.Active
Al_PressByPass.Active
Al_TempByPass.Active
Al_Press.Active
Al_MissModel.Active
Al_WTS.Active
Al_WPrb_1÷ 8.Active
Al_WPrbMain_1.Active
Al_WPrbLim_1.Active
Al_WPrbMain_2.Active
Al_WPrbLim_2.Active
Al_NetUnit_1÷ 4.Active
Al_Maint_50.Active
Wr_Maint_1000.Active
Al_Maint_3000.Active
UnitStatus
5: STAND BY 10: MANUAL MODE
6: PRODUCTION 11: READY BACKUP
7: ALARM 12: SWITCH OFF
9: WASH
ReqMsk_1
ReqMsk_2
Prod_1
Prod_2
WProd_1
WProd_2
MainPrb_1
MainPrb_2
LimPrb_1
LimPrb_2
PressByPass
Press
32
Size
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
2
2
2
2
2
2
2
2
2
2
