12.3.4 UL version blower datasheet
Single blower units (for wall-mounting) UL version
Dimensions
Weight
Packaged dimensions
Packaged weight
Delivery and storage temperature
Operating temperature
Ingress protection (IP)
Conformity
Water fitting
Water outlet
Number of nozzles
Flow-rate (depending on the type of nozzles)
Power supply
Fan total air flow-rate
Blower connection cable
Maximum number of blower units (connected to one cabinet)
Double blower units (for mounting in centre of corridor) UL version
Dimensions
Weight
Packaged dimensions
Packaged weight
Delivery and storage temperature
Operating temperature
Ingress protection (IP)
Conformity
Water fitting
Water outlet
Number of nozzles
Flow-rate (depending on the type of nozzles)
Power supply
Fan total air flow-rate
Blower connection cable
Maximum number of blower units (connected to one cabinet)
DLA02UF*00
640 x 200 x 180 mm
4.5 kg
755 x 235 x 295 mm
5.7 kg
-10/50°C 0-90%
2/40°C 5-95%
IP10
UL
M16x1.5 Male
M16x1.5 Male
2
3.0 l/h - 5.6 l/h - 8.0 l/h
120 Vac 60 Hz
360 mc/h
AWG 14 with UA050%
AWG 12 with UA090%
12
DLA04UB*00
640 x 200 x 400 mm
9.2 kg
755 x 470 x 295 mm
11.4 kg
-10/50°C 0-90%
2/40°C 5-95%
IP10
UL
M16x1.5 Female
M16x1.5 Female
4
6.0 l/h – 11.2 l/h – 16.0 l/h
120 Vac 60 Hz
720 m3/h
AWG 14 with UA050%
AWG 12 with UA090%
6
45 "humiFog direct" +0300073EN rel. 1.2 - 02.05.2019
ENG
DLA04UF*00
940 x 200 x 180 mm
5.6 kg
1050 x 235 x 295 mm
7.4 kg
-10/50°C 0-90%
2/40°C 5-95%
IP10
UL
M16x1.5 Male
M16x1.5 Male
4
6.0 l/h – 11.2 l/h – 16.0 l/h
120 Vac 60 Hz
720 mc/h
AWG 14 with UA050%
AWG 12 with UA090%
6
Tab. 12.k
DLA08UB*00
940 x 200 x 400 mm
15.5 kg
1050 x 470 x 295 mm
18.0 kg
-10/50°C 0-90%
2/40°C 5-95%
IP10
UL
M16x1.5 Female
M16x1.5 Female
8
12.0 l/h – 22.4 l/h – 32 l/h
120 Vac 60 Hz
1,440 m3/h
AWG 14 with UA050%
AWG 12 with UA090%
3
Tab. 12.l
