Carel humiFog direct UA040DD101 User Manual page 37

Alarm Code Cause
Wireless p. 4 offline ALP11 No communication
Wireless p. 5 offline ALP12 No communication
Wireless p. 6 offline ALP13 No communication
Wireless p. 7 offline ALP14 No communication
Wireless p. 8 offline ALP15 No communication
Main probe 1 offline ALP16 No communication
Limit probe 1 offline ALP17 No communication
Main probe 2 offline ALP18 No communication
Limit probe 2 offline ALP19 No communication
Unit 1 alarm ALN01 Alarm on unit no. 1 in
Unit 2 alarm ALN02 Alarm on unit no. 2 in
Unit 3 alarm ALN03 Alarm on unit no. 3 in
Unit 4 alarm ALN04 Alarm on unit no. 4 in
High bypass temp. WRA12 Water temperature in
1000h maintenance WRA14 Pump check request
Low pressure -
Possible solution
Check:
with probe 4 • probe/access point binding
• battery charge
• probe signal level
Check:
with probe 5 • probe/access point binding
• battery charge
• probe signal level
Check:
with probe 6 • probe/access point binding
• battery charge
• probe signal level
Check:
with probe 7 • probe/access point binding
• battery charge
• probe signal level
Check:
with probe 8 • probe/access point binding
• battery charge
• probe signal level
Check:
with all the wireless • probe connections
probes - main control • probe/access point binding
in zone 1 • access point power supply
Check:
with all the wireless • probe connections
probes - limit control • probe/access point binding
in zone 1 • access point power supply
Check:
with all the wireless • probe connections
probes - main control • probe/access point binding
in zone 2 • access point power supply
Check:
with all the wireless • probe connections
probes - limit control • probe/access point binding
in zone 2 • access point power supply
Only if network function is active
network Carry out the checks based on the alarm displayed on the
unit in question
Only if network function is active
network Carry out the checks based on the alarm displayed on the
unit in question
Only if network function is active
network Carry out the checks based on the alarm displayed on the
unit in question
Only if network function is active
network Carry out the checks based on the alarm displayed on the
unit in question
Possible extended recirculation of water through the
bypass > 50°C bypass. Check:
• that the humidification capacity set on screen Dc18 is
equal to the no. of nozzles x capacity of each nozzle;
• that the zone can deliver a flow-rate of water ≥ the
minimum flow-rate supplied by the pump;
• that the NTC probe is connected to terminals J5.2-J5.3
• Check pump wear and oil every 1000 operating hours
Pressure measured by Possible small water leaks at the outlet, check tightness
probe RHP < 60 bars of the hose fittings and make sure there are no leaks from
with pump running the drain solenoid valves DR1 and DR2.
Check that the pump is able to deliver the flow-rate
required to satisfy the load provided by the nozzles.
37 "humiFog direct" +0300073EN rel. 1.2 - 02.05.2019
ENG
Reset Alarm relay Action
Automatic Active Signal
Automatic Active Signal
Automatic Active Signal
Automatic Active Signal
Automatic Active Signal
Automatic Active Signal
Automatic Active
Automatic Active Signal
Automatic Active Signal
Automatic Active Signal
Automatic Active Signal
Automatic Active Signal
Automatic Active Signal
- Not active Warning
Manual Not active Signal
- Inactive Warning
Tab. 10.a
