ELECTRICAL SPECIFICATIONS
Power supply
Cabinet power cable
Power (cabinet only, without blowers)
Current (cabinet only, without blowers)
Maximum power (cabinet with blowers)
Maximum current (cabinet with blowers)
FLA (Full Load Amperes)
SCCR (Short Circuit Current Rating)
Minimum cable size required for blower power supply
WATER CIRCUIT SPECIFICATIONS
Required feedwater quality
Required feedwater conductivity
Required feedwater pressure
Water inlet connection
Water drain connection
Water outlet connection
Water outlet pressure
Maximum capacity
FUNCTIONAL SPECIFICATIONS
Number of probes allowed (temperature and/or humidity)
External signal or type of probes
Multi-probe
Webserver
Serial communication (via Ethernet and/or via RS485)
12.3.3 CE version blower datasheet
Single blower units (for wall-mounting)
Dimensions
Weight
Packaged dimensions
Packaged weight
Delivery and storage temperature
Operating temperature
Ingress protection (IP)
Conformity
Water fitting
Water outlet
Number of nozzles
Flow-rate (depending on the type of nozzles)
Power supply
Fan total air flow-rate
Blower connection cable
Maximum number of blower units (connected to one cabinet)
Double blower units (for mounting in centre of corridor) CE version
Dimensions
Weight
Packaged dimensions
Packaged weight
Delivery and storage temperature
Operating temperature
Ingress protection (IP)
Conformity
Water fitting
Water outlet
Number of nozzles
Flow-rate (depending on the type of nozzles)
Power supply
Fan total air flow-rate
Blower connection cable
Maximum number of blower units (connected to one cabinet)
"humiFog direct" +0300073EN rel. 1.2 - 02.05.2019
UA050DU*01
120 Vac 60 Hz single-phase
AWG 14
0.28 kW (single-zone)
0.38 kW (two zones)
5.0 A (single-zone)
5.8 A (two zones)
0.74 kW (single-zone)
0.84 kW (two zones)
10.3 A (single-zone)
11.0 A (two zones)
0.25HP/180W 4.2 A
5 kA
AWG 14
UA050DU*01
demineralised
5-80 µS/cm
3-8 bars
3/4" GAS F
1/2" GAS F
1/4" GAS F
70 bars
50 l/h
UA050DU*01
1 (single-zone) + limit
2 (two-zone) + limit
0-10 V, 4-20 mA, 0-1 V, 2-10 V, 0-20 mA, NTC probe 0-10 V, 4-20 mA, 0-1 V, 2-10 V, 0-20 mA, NTC probe
available
available
Modbus, BACnet
3.0 l/h - 5.6 l/h - 8.0 l/h
6.0 l/h – 11.2 l/h – 16.0 l/h
44
UA090DU*01
120 Vac 60 Hz single-phase
0.47 kW (single-zone)
0.57 kW (two zones)
8.0 A (single-zone)
8.8 A (two zones)
0.93 kW (single-zone)
1.03 kW (two zones)
13.3 A (single-zone)
14.0 A (two zones)
0.5HP/370W 7.1 A
UA090DU*01
demineralised
5-80 µS/cm
3/4" GAS F
1/2" GAS F
1/4" GAS F
UA090DU*01
1 (single-zone) + limit
2 (two-zone) + limit
Modbus, BACnet
DLA02DF*00
640 x 200 x 180 mm
4.5 kg
755 x 235 x 295 mm
5.7 kg
-10/50°C 0-90%
2/40°C 5-95%
IP10
CE
M16x1.5 Male
M16x1.5 Male
2
6.0 l/h – 11.2 l/h – 16.0 l/h
230 Vac 50 Hz
300 m3/h
AWG 14
12
DLA04DB*00
640 x 200 x 400 mm
9.2 kg
755 x 470 x 295 mm
11.4 kg
-10/50°C 0-90%
2/40°C 5-95%
IP10
CE
M16x1.5 Female
M16x1.5 Female
4
12.0 l/h – 22.4 l/h – 32 l/h
230 Vac 50 Hz
600 m3/h
AWG 14
6
AWG 12
5 kA
AWG 12
Tab. 12.f
3-8 bars
70 bars
90 l/h
Tab. 12.g
available
available
Tab. 12.h
DLA04DF*00
940 x 200 x 180 mm
5.6 kg
1050 x 235 x 295 mm
7.4 kg
-10/50°C 0-90%
2/40°C 5-95%
IP10
CE
M16x1.5 Male
M16x1.5 Male
4
230 Vac 50 Hz
600 m3/h
AWG 14
6
Tab. 12.i
DLA08DB*00
940 x 200 x 400 mm
15.5 kg
1050 x 470 x 295 mm
18.0 kg
-10/50°C 0-90%
2/40°C 5-95%
IP10
CE
M16x1.5 Female
M16x1.5 Female
8
230 Vac 50 Hz
1,200 m3/h
AWG 14
3
Tab. 12.j
