Page 1 Ã Ã KRPH6WHDP XPLGLILFDWRUH 80 80 KXPLGLILHU 0DQXDOH G¶LQVWDOOD]LRQH H XVR ,QVWDOODWLRQ DQG RSHUDWLRQ PDQXDO...
Page 3: Table Of Contents
&217(176 02'(/6 $1' '(6&5,37,21 2) 7+( &20321(176 Models ..................................27 Description of the components ..........................27 02817,1* Receipt and storage..............................29 Positioning................................29 Fastening ................................. 29 Removal and reassembly of the front cover ......................30 :$7(5 &211(&7,216 Characteristics of the supply water..........................
Page 4 GLVSRVHG RI DFFRUGLQJ WR WKH ORFDO VWDQGDUGV RQ ZDVWH GLVSRVDO :DUUDQW\ RQ PDWHULDOV \HDUV IURP WKH GDWH RI SURGXFWLRQ H[FOXGLQJ WKH FRQVXPDEOH SDUWV &HUWLILFDWLRQ the quality and safety of Carel products are guaranteed by Carel’s ,62 certified design and production system, as well as the...
Page 5: Models
• D: power supply voltage 230 Vac, single phase. 'HVFULSWLRQ RI WKH FRPSRQHQWV TRANSFORMER FUSE-HOLDER ON/OFF SWITCH - MANUAL CYLINDER DRAIN SWITCH CONTROL BOARD POWER CABLE TERMINAL BLOCK SUPPLY DRAIN ELECTROVALVE ELECTROVALVE )LJ cod. carel +030221900 rel. 2.0 dated 05/03/01...
Page 6 – overflow high level electrodes steam outlet electrodes cylinder casing bottom filter drain electrovalve 7DEOH )LJ cod. carel +030221900 rel. 2.0 dated 05/03/01...
Page 7: Fastening
Finally, fasten the appliance to the wall using the central hole in the rear part of the base; this can be easily reached from below. For the weights and dimensions, see 'LPHQVLRQV DQG ZHLJKWV and Fig. 10.1.1. cod. carel +030221900 rel. 2.0 dated 05/03/01...
Page 8: Checks
With reference to Fig. 2.3.1, to UHPRYH the front cover of the humidifier, proceed as follows: 1. turn the oval-shaped plate with the Carel logo 90°, revealing the head of the earth screw below; 2. remove the screw using a screwdriver;...
Page 9 1. the use of well water, industrial water or water from cooling circuits and, in general, any potentially chemically or bacteriologically contaminated water; 2. the addition to the water of disinfectants or corrosion inhibiters, as these are potential irritants. cod. carel +030221900 rel. 2.0 dated 05/03/01...
Page 10 To simplify installation, it is recommended to use Carel flexible tubing with an internal diameter of 6 mm and an external diameter of 8 mm (code 1312350APN) and the ¾G revolving fitting, either straight (code 9995727ACA)
Page 11 • drain pipe resistant to temperatures of 100°C; • minimum internal diameter of the drain tubing of 36 mm; • minimum slope of the drain tubing greater than or equal to 5°; • electrically QRQFRQGXFWLYH sleeve. cod. carel +030221900 rel. 2.0 dated 05/03/01...
Page 12 For steam distribution into air ducts, the steam distributor must be sized according to the power of the humidifier and the cross-section of the ducting. For this purpose, Carel supplies two ranges of linear distributors: one made from aluminium with plastic ends (type E) and the other, top-line range, made completely from AISI 304 stainless steel with double chamber (type L).
Page 13 D 22 fori D 5 N.B. in the case of steam tubing with an internal steam inlet diameter of 30 mm, remove the 22 mm steam inlet )LJ cod. carel +030221900 rel. 2.0 dated 05/03/01...
Page 14 ,QVWDOODWLRQ RI WKH VWHDP SLSH The humidifier must be connected to the distributor using a pipe suitable for this purpose, such as the Carel flexible pipe. The use of unsuitable tubing may cause weakening and cracking and consequently steam leaks.
Page 15 • the gradient of the condensate pipe is at least 5° at every point; • the condensate pipe always follows a downwards path and features a drain trap (filled with water before starting operation) to avoid steam being released. cod. carel +030221900 rel. 2.0 dated 05/03/01...
Page 16: Checks
=50 Ω; V input signal from humidistat imposes an external NO contact; R =10Vdc; I =1mAdc =50 Ω; V remote enabling input imposes an external NO contact; R =24Vdc; I =10mAdc 7DEOH cod. carel +030221900 rel. 2.0 dated 05/03/01...
Page 17: Power Supply Voltage
• the electrical connections have been performed as indicated in the diagrams; • the power cable is fastened using the tear-proof fairlead; • terminals AB-AB are connected by jumper or connected to an enable-operation contact. cod. carel +030221900 rel. 2.0 dated 05/03/01...
Page 18 PHDQLQJ )LJ green left power on yellow central production in progress right signals and alarms. These events are indicated by flashes. Please refer to Table 7.1 for details 7DEOH )LJ cod. carel +030221900 rel. 2.0 dated 05/03/01...
Page 19: Checks
In the event of malfunction of the drain electrovalve, the cylinder can be emptied manually by removing it from the manifold connection and slowly pouring the water into the bottom collection tank. cod. carel +030221900 rel. 2.0 dated 05/03/01...
Page 20: Shut-Down
10 seconds, turn it on again: if the alarm total shut- quick flashes error does not disappear, contact Carel’s service centre down cylinder full with turn off the machine and check whether the fill electrovalve licks or there is...
Page 21 4. the steam outlet pipe is not properly 4. check the fastening of the pipe clamps on the fastened to the cylinder steam outlet 7DEOH cod. carel +030221900 rel. 2.0 dated 05/03/01...
Page 22: Automatic Draining
The “Cylinder exhausted” alarm can be disabled by switching ON dip no. 4 on the block of 4 dip-switches near the screw terminal block (see Fig. 5.3.1). Dip-switches no. 2 and 3 are meaningless in homeSteam and their positions have no effect. 1% 1(9(5 02',)< 7+( 326,7,21 2) 7+( ',36:,7&+(6 1$0(' ³7$ 5$7(´ cod. carel +030221900 rel. 2.0 dated 05/03/01...
Page 23 :$51,1*: turn off the instrument before touching the cylinder in case of water leaks, since water could be under voltage. cod. carel +030221900 rel. 2.0 dated 05/03/01...
Page 24 EHHQ FDUULHG RXW FRUUHFWO\ DQG WKH FRUUHVSRQGLQJ VHDOV KDYH EHHQ XVHG 5HVWDUW WKH PDFKLQH DQG SHUIRUP D QXPEHU RI VXSSO\ DQG GUDLQ F\FOHV IURP WR WKHQ FKHFN IRU DQ\ ZDWHU OHDNV cod. carel +030221900 rel. 2.0 dated 05/03/01...
Page 25 **: specify the humidifier model, either UM001 or UM003 6SDUH SDUWV IRU VSHFLDO DSSOLFDWLRQV The following special parts are to be ordered separately from the standard humidifier. 'HVFULSWLRQ FRGH cylinder for low conductivity BL0S1E00H0 (125÷500 µS/cm) 7DEOH cod. carel +030221900 rel. 2.0 dated 05/03/01...
Page 26 & SDFNDJHG ZHLJKWV NJ HPSW\ 13.5 LQVWDOOHG 16.5 : in normal operating conditions, filled with water 7DEOH )LJ Carel reserves the right to modify or change its products without prior notice. cod. carel +030221900 rel. 2.0 dated 05/03/01...
