12.3 Datasheets

12.3.1 CE version cabinet datasheet
PHYSICAL SPECIFICATIONS
Dimensions
Weight
Packaged dimensions
Packaged weight
Delivery and storage temperature and humidity
Operating temperature and humidity
IP rating
Conformity
ELECTRICAL SPECIFICATIONS
Power supply
Cabinet power cable
Power (cabinet only, without blowers)
Current (cabinet only, without blowers)
Maximum power (cabinet with blowers)
Maximum current (cabinet with blowers)
FLA (Full Load Amperes)
SCCR (Short Circuit Current Rating)
Minimum cable size required for blower power supply
WATER CIRCUIT SPECIFICATIONS
Required feedwater quality
Required feedwater conductivity
Required feedwater pressure
Water inlet connection
Water drain connection
Water outlet connection
Water outlet pressure
Maximum capacity
FUNCTIONAL SPECIFICATIONS
Number of probes allowed (temperature and/or humidity)
External signal or type of probes
Multi-probe
Web server
Serial communication (via Ethernet and/or via RS485)
12.3.2 UL version cabinet datasheet
PHYSICAL SPECIFICATIONS
Dimensions
Weight
Packaged dimensions
Packaged weight
Delivery and storage temperature and humidity
Operating temperature and humidity
IP rating
Conformity
UA040DD*01
630 x 800 x 300 mm
60 kg (single-zone)
64 kg (two zones)
720 x 1020 x 460 mm
64 kg (single-zone)
68 kg (two zones)
-10/50°C 0-90% rH
2/40°C 5-95% rH
IP20
EN60204-1 2006; EN61000-6-2 2006;
EN61000-6-4 2007
UA040DD*01
230 V 50 Hz single-phase
AWG 14
0.28 kW (single-zone)
0.38 kW (two zones)
2.5 A (single-zone)
3.0 A (two zones)
0.81 kW (single-zone)
0.91 kW (two zones)
4.8 A (single-zone)
5.0 A (two zones)
0.25HP/180W 2 A
5 kA
AWG 14
UA040DD*01
demineralised
5-80 µS/cm
3-8 bars
3/4" GAS F
1/2" GAS F
1/4" GAS F
70 bars
40 l/h
UA040DD*01
1 (single-zone) + limit
2 (two-zone) + limit
0-10 V, 4-20 mA, 0-1 V, 2-10 V, 0-20 mA, NTC probe
available
available
Modbus, BACnet
UA050DU*01
630 x 800 x 300 mm
60 kg (single-zone)
64 kg (two zones)
720 x 1020 x 460 mm
64 kg (single-zone)
68 kg (two zones)
-10/50°C 0-90% rH
2/40°C 5-95% rH
IP20
UL998
43
UA080DD*01
630 x 800 x 300 mm
64 kg (single-zone)
68 kg (two zones)
720 x 1020 x 460 mm
68 kg (single-zone)
72 kg (two zones)
-10/50°C 0-90% rH
2/40°C 5-95% rH
IP20
EN60204-1 2006; EN61000-6-2 2006;
EN61000-6-4 2007
UA080DD*01
230 V 50 Hz single-phase
AWG 14
0.47 kW (single-zone)
0.57 kW (two zones)
3.5 A (single-zone)
4.0 A (two zones)
1.0 kW (single-zone)
1.1 kW (two zones)
7.1 A (single-zone)
7.6 A (two zones)
0.5HP/370W 3 A
5 kA
AWG 14
UA080DD*01
demineralised
5-80 µS/cm
3-8 bars
3/4" GAS F
1/2" GAS F
1/4" GAS F
70 bars
80 l/h
UA080DD*01
1 (single-zone) + limit
2 (two-zone) + limit
0-10 V, 4-20 mA, 0-1 V, 2-10 V, 0-20 mA, NTC probe
available
available
Modbus, BACnet
UA090DU*01
630 x 800 x 300 mm
64 kg (single-zone)
68 kg (two zones)
720 x 1020 x 460 mm
68 kg (single-zone)
72 kg (two zones)
-10/50°C 0-90% rH
2/40°C 5-95% rH
IP20
UL998
"humiFog direct" +0300073EN rel. 1.2 - 02.05.2019
