7.3.1 Transmit Buffer

Index Sub-index
2000h -
0
1
2
...
128
2001h -
0
1
2
...
128
2002h -
0
1
2
...
128
2003h -
0
1
2
...
126
2010h -
0
1
2
...
128
2011h -
0
1
2
...
128
2020h -
0
1
2
...
127
Anybus X-gateway CANopen - PROFIBUS
Doc.Rev. 1.02
Type Access Name and Description
STRUCT Transmit Byte 2-129 area
U8 RO 128
U8 RW Transmit Byte 2
U8 RW Transmit Byte 3
... ... ...
U8 RW Transmit Byte 129
STRUCT Transmit Byte 130-257 area
U8 RO 128
U8 RW Transmit Byte 130
U8 RW Transmit Byte 131
... ... ...
U8 RW Transmit Byte 257
STRUCT Transmit Byte 258-385 area
U8 RO 128
U8 RW Transmit Byte 258
U8 RW Transmit Byte 259
... ... ...
U8 RW Transmit Byte 385
STRUCT Transmit Byte 386-511 area
U8 RO 126
U8 RW Transmit Byte 386
U8 RW Transmit Byte 387
... ... ...
U8 RW Transmit Byte 511
STRUCT Transmit Word 2-129 area
U8 RO 128
U16 RW Transmit Word 2
U16 RW Transmit Word 3
... ... ...
U16 RW Transmit Word 129
STRUCT Transmit Word 130-256 area
U8 RO 127
U16 RW Transmit Word 130
U16 RW Transmit Word 131
... ... ...
U16 RW Transmit Word 256
STRUCT Transmit Long 2-128 area
U8 RO 127
U32 RW Transmit Long 2
U32 RW Transmit Long 3
... ... ...
U32 RW Transmit Long 128
