7.2.3 Network Management Objects

The NMT master controls the states of the connected network participants, the NMT slaves. It moni-
tors the devices and reports to the application, for example if an NMT slave fails. Please refer to the
CANopen specification, see "Related Documents" on page 1. In more complex systems several devices
are able to perform as master, which means that the configuration must have an entry defining which
device will act as master.
Once configured, the objects carry all information needed for the module to act on the network and the
application does not need to be accessed to obtain this information. This results in a substantial reduc-
tion of the overall implementation and maintenance effort when implementing multiple applications.
Index Object Name Sub-Index Description
1F80h NMT Start-up
1F81h Slave Assign-
ment
1F82h Request NMT ARRAY
1F83h Request
Guarding
1F84h Device Type
Identification
1F85h Vendor Identifi-
cation
1F86h Product Code ARRAY
1F87h Revision
Number
1F88h Serial Number ARRAY
1F89h Boot Time
Anybus X-gateway CANopen - PROFIBUS
Doc.Rev. 1.02
- Defining whether the device is the
NMT Master
ARRAY Module list: Entry of all slaves to
be managed, including guarding
values and the entry of actions to
be taken in event of guarding
errors.
Remote control initiation of NMT
services. For example, tools can
use this to request intentional start/
stop of individual slaves. Remote
query of the current state.
ARRAY Remote control start/stop of guard-
ing. Remote query of the current
state
ARRAY Expected device types for the
slaves
ARRAY Vendor identifications for the
slaves
Product codes for the slaves
ARRAY Revision numbers for the slaves
Expected serial numbers for the
slaves
VAR The maximum time between the
start of the boot process and the
signaling of succesful boot of all
mandatory NMT slaves. After this
time LSS services are initiated.
CANopen Supported Objects 33
Type Access
U32 RW
U32 Sub 0: RO
Sub 1 - 127: RW
U8 Sub 0: RO
Sub 1 - 127: RW
Sub 128: WO
U8 Sub 0: RO
Sub 1 - 127: RW
Sub 128: WO
U32 Sub 0: RO
Sub 1 - 127: RW
U32 Sub 0: RO
Sub 1 - 127: RW
U32 Sub 0: RO
Sub 1 - 127: RW
U32 Sub 0: RO
Sub 1 - 127: RW
U32 Sub 0: RO
Sub 1 - 127: RW
U32 RW
