6 Specifications

Chapter Scope

6.1 RXi Box IPC-XP Specifications

Temperature
Ambient temperatures and humidity values for the RXi Box IPC-XP:
Order – Code Temp.
High Temperature
- Storage
- Operating
a
RXxxxxE, RXxxxxN, 17W CPU
RXxxxxF, 25W CPU
RXxxxxQ, 35W CPU
Low Temperature
- Storage
- Operating
Relative Humidity
- Storage, Operating
For more temperature information and extended temperature range please ask our support team.
a

Table 20: Environment conditions

The RXi Box IPC-XP is designed to meet these shock and vibration values:
Vibration
- Spectrum
- Acceleration
Shock
- half sine or saw tooth
- Duration
Table 21: Shock & vibration parameters
Maximum height usage for the RXi Box IPC-XP is specified in the table below:
Maximum height
- Operating
- Storage

Table 22: Maximum height usage

PACSystems RXi Box IPC-XP Hardware Reference Manual
Internal
This chapter gives some useful information when using an RXi Box IPC-XP for the first
time. It might be also useful to read this chapter carefully, when problems came up in
using the RXi Box IPC-XP.
Level A
+70 °C
+60 °C
+55 °C
+50 °C
-40 °C
0 °C
up to 95% non-condensing
Level A
3 to 100 Hz
1 grms
20 g
11 ms
Level A
2000 m
GFK-2990 57
