2.4 ESD

Electrostatic Discharge Notice
Electrostatic Discharge Notice The discharge of static electricity, known as Electro Static Discharge or ESD, is a
major cause of electronic component failure. The RXi Box IPC-XP has been packed in a static-safe bag which
protects the IPC from ESD while the IPC is in the bag. Before removing the RXi Box IPC-XP or any other
electronic product from its static-safe bag, be prepared to handle it in a static-safe environment.
You should wear a properly-functioning anti-static strap and ensure you are fully grounded. Any surface upon
which you place the unprotected RXi Box IPC-XP should be static-safe, usually facilitated by the use of anti-
functioning properly, extreme care should be taken to avoid ʹzappingʹ the board with ESD. You should be
static mats. From the time the board is removed from the anti-static bag until it is in the card cage and
aware that you could ʹzapʹ the board without you knowing it; a small discharge, imperceptible to the eye and
touch, can often be enough to damage electronic components. Extra caution should be taken in cold and dry
weather when static easily builds up.
Only after ensuring that both you and the surrounding area are protected from ESD, carefully remove the
board or module from the shipping carton by grasping the module on its edges. Place the board, in its
antistatic bag, flat down on a suitable surface. You may then remove the board from the anti-static bag by
tearing the ESD warning labels.

2.5 Initial Inspection

After unpacking the RXi Box IPC-XP, you should inspect it for visible damage that could have occurred during
shipping or unpacking. If damage is observed (usually in the form of bent component leads or loose socketed
components), contact GE Intelligent Platforms for additional instructions. Depending on the severity of the
damage, it may necessary to return the product to the factory for repair.
DO NOT apply power to the box if it has visible damage!
Doing so may cause further, possibly irreparable damage, as well as introduce a fire
or shock hazard.
PACSystems RXi Box IPC-XP Hardware Reference Manual
Internal
WARNING
GFK-2990 21
