3.7 Installation of a Mini PCIe add-on card

The information described in this chapter is for service technician only!
Mini PCIe cards are installed into the RXi Box IPC-XP by as shown:
Mini PCIe slot full size, empty
Insert Mini-PCIe module

Figure 9: Installation of Mini-PCIe module

PACSystems RXi Box IPC-XP Hardware Reference Manual
Internal
ATTENTION
Mini PCIe slot half size, empty
Mounted Mini-PCIe module
GFK-2990 34
