4.3.1 LEDs

The RXi Box IPC-XP has a set of status LEDs for indicating various functions.

Figure 18: front panel LEDs

Status.
Some power is applied
Valid power is applied, CPU is in any standby or off state amber
Valid power, CPU is powered

Table 4: Front Power LED

Status.
No hard disk activity
Hard disk activity on SATA or CFlash

Table 5: Hard disk activity LED

Status.
User Status LED
a
a
On RXM1x2 this LED shows the status of the battery coin cell within the system. It lights red when the battery is exhausted. After
replacement of the battery, the red LED must be reset within UEFI SETUP.

Table 6: User status LED

Status.
Temperature below limit
Temperature above limit

Table 7: Over temperature LED

PACSystems RXi Box IPC-XP Hardware Reference Manual
Internal
red
green
off
amber
User Status LED (amber by default)
off
red (default temperature limit is set to 85 °C)
GFK-2990 42
