4.3.10 Internal SATA Slot

Inside the RXi Box IPC-XP there is a bay for mounting a standard SATA 2.5 inch drive.
Drives with rotating media may be used if they withstand the intended temperature
range inside the RXi Box IPC-XP. The use of Solid State Disk is recommended.

4.3.11 CFast Slot

On the front of the RXi Box IPC-XP there a CFast Type I flash slot is available. Standard CFast cards can be used
for storage of data or the operating system. The device is connected to a standard SATA port of the COM
module.

Figure 27: CFast connector

PACSystems RXi Box IPC-XP Hardware Reference Manual
Internal
NOTE
GFK-2990 50
