4 Hardware

Chapter Scope

4.1 Overview for RXE and RXMxx0 based on the carrier CEC04

Power
Conn
Transc
RS-232
Transc
RS-232
optional
Transc
RS-422/
RS485
Transc
optional
RS-422/
RS485
CFast
DP
USB
USB
USB
USB
Magnetics
RJ-45
Magnetics
RJ-45
Magnetics
RJ-45
Magnetics
RJ-45
Magnetics
RJ-45

Figure 14: Hardware Overview

PACSystems RXi Box IPC-XP Hardware Reference Manual
Internal
This chapter describes the hardware of the RXi Box IPC-XP.
DC-DC Conversion
UART
4-ch
Opto-
coupl
Opto-
coupl
COM Express Module
10/100/1000
Ethernet
MAC/PHY
(i210)
10/100/1000
Ethernet
MAC/PHY
PCIe Switch
(i210)
10/100/1000
Ethernet
MAC/PHY
(i210)
10/100/1000
Ethernet
MAC/PHY
(i210)
x1 PCIe Gen1
Riser Connector
Pericom
PCIe
508
to PCI
Switch
2 or 4 PCI slots
mini PCI-e
Fan
Controller
FAN
(optional)
FPGA
NVRAM
NVRAM Option
GFK-2990 39
