Table 19: Pci Routing - GE PACSystems RXi-XP IPC Hardware Reference Manual

Function
Ether #4
Ether #3
Ether #2
Ether #1
PCIe Serial
Mini PCle
On Riser card 043/044
(RXx2x0, RXx4x0)
PCIe to PCI bridge
NVSRAM
PCI Slot #1
PCI Slot #2
PCI Slot #3
PCI Slot #4
Riser card PERC01/02
(RXx6x0, RXx5x0)
PCIe Switch
PCIe Slot #1
PCIe Slot #2
PCIe to PCI bridge
NVSRAM
PCI Slot #1
PCI Slot #2

Table 19: PCI Routing

PACSystems RXi Box IPC-XP Hardware Reference Manual
Internal
Connected to Vendor
front 8086
front 8086
front 8086
front 8086
Serial 12D8
PCI Slots 12D8
1533
PCIe Slots 10B5
PCI Slots 12D8
1533
Device Bus/Dev/Func
1533 3/00/0
1533 4/00/0
1533 5/00/0
1533 6/00/0
7954 9/00/0
A/00/0
E113 7/00/0
3AD2 8/05/0
8/06/0
8/07/0
8/08/0
8/09/0
8606 7/00/0
8/00/0
9/00/0
E113 A/00/0
3AD2 B/05/0
B/06/0
B/07/0
GFK-2990 55
