4.3.4 Ethernet Interface (Eth1, Eth2, Eth3, Eth4, Eth5; on RXM1x2 Eth1, Eth2, Eth3)

Figure 21: Ethernet Interface

The Ethernet interfaces require usage of CAT 5 cable for proper operation with 100/1000BaseT.
Name 10/100base
TxD+
TxD-
RxD+
NC
NC
RxD-
NC
NC

Table 8: Front Power LED

Two LEDs (green and yellow) are integrated in each of the RJ45 connector. These LEDs indicate the link status
and activity of the interface.
LED
Right green LED
On
Off
Left yellow LED
On, blink
Off

Table 9: Ethernet LEDs

PACSystems RXi Box IPC-XP Hardware Reference Manual
Internal
Name 1000base
LP_DA+
LP_DA-
LP_DB+
LP_DC+
LP_DC-
LP_DB-
LP_DD+
LP_DD-
Function
Link is active
No link
Tx/Rx activity
No activity
1
2
3
4
5
6
7
8
GFK-2990 44
