The PACSystems RXi product line of industrial computers provides an advanced, high-performance computing platform. The
PACSystems Box IPC delivers the flexibility of a PC with the industrial ruggedness of traditional automation controllers.
Built with an open and scalable architecture, the RXi platform enables easy connectivity and allows you to maximize application
reusability—supporting your current and future needs for business growth.
These small form factor IPCs provide a number of features to support computing applications in demanding environments:
•
Dual core 1.0 GHz VIA processor
•
Multiple Gigabit Ethernet interfaces provide network implementation flexibility.
•
Built-in Data Storage – Internal disks provide highly reliable local long-term data retention.
•
USB and SD Card interfaces enable program loading, serial communications and removable data storage through
standard devices.
Ordering Information
Catalog Number
ICRXIBN7F001A
ICRXIBN7E001A
ICRXIBN7M001A
ICRXIBN0F001A
ICRXIBN0E001A
ICRXIBN0M001A
IC690ACC001
ICRXIACCBPL
RXi Box IPC with Embedded 64 GB mSATA SSD and Windows 7 Professional, SP1
RXi Box IPC with Embedded 32 GB mSATA SSD and Windows 7 Professional, SP1
RXi Box IPC with 250 GB Magnetic SATA HDD and Windows 7 Professional, SP1
RXi Box IPC with Embedded 64 GB mSATA SSD, no OS
RXi Box IPC with Embedded 32 GB mSATA SSD, no OS
RXi Box IPC with 250 GB Magnetic SATA HDD, no OS
Real Time Clock (RTC) battery, included with IPC
Optional Backplate for DIN-rail mounting
©2014 - 2016 GE's Automation & Controls, Inc. All Rights Reserved
*Trademark of GE's Automation & Controls, Inc.
All other brands or names are property of their respective holders.
PACSystems* RXi
Industrial PC (IPC)
Quick Start Guide
Description
Advertisement
Table of Contents
Related Manuals for GE PACSystems RXi Series
Summary of Contents for GE PACSystems RXi Series
- Page 1 Real Time Clock (RTC) battery, included with IPC ICRXIACCBPL Optional Backplate for DIN-rail mounting ©2014 - 2016 GE’s Automation & Controls, Inc. All Rights Reserved *Trademark of GE’s Automation & Controls, Inc. All other brands or names are property of their respective holders.
-
Page 2: General Specifications
PACSystems RXi IPC QSG GFK-2784J General Specifications Item Specification IPC: 191.8 x 115.6 x 81.3 mm (7.55 x 4.55 x 3.2 in) Dimensions Backplate: 226 x 137 x 12 mm (8.90 x 5.39 x 0.47 in) IPC: 1.814 Kg (4 lbs) Weight Backplate: 0.454 Kg (1 lb) Processor... -
Page 3: Emc Requirements
Before attempting to power up the RXi Display for the first time, inspect the unit for loose or damaged components. If damage is observed (such as bent component leads or loose components), contact GE. Depending on the severity of the damage, it may be necessary to return the product to the factory for repair. -
Page 4: Initial Startup
PACSystems RXi IPC QSG GFK-2784J Initial Startup You will need the following: 24 VDC, 48 W power supply, Class 2 or LPS VGA-compatible video monitor USB-compatible keyboard Power cord with 28 – 16 AWG wires USB-compatible mouse (optional) The product is supplied with a Phoenix Contact part number 1827716 or 1851245 (spring loaded/quick release) power terminal block for use with a power supply. -
Page 5: Shutting Down The Computer
PACSystems RXi IPC QSG GFK-2784J Shutting Down the Computer Caution For ICRXIBN7xxxxx Models, to avoid damaging files, always shut down Windows software before removing power from the IPC. Caution For ICRXIBN7xxxxx Models, do not disconnect external devices, such as a flash drive or external DVD drive without first using the Windows Safely Remove Hardware feature to eject the device. -
Page 6: Indicators And Connectors
PACSystems RXi IPC QSG GFK-2784J Indicators and Connectors Power On/Off Switch Audio Connector and Status Indicator Indicators SD Card Slot Blue, blinking – Booting Blue, slow fade – S3 Sleep Green, solid – Running Red, solid – Fault Connectors... - Page 7 PACSystems RXi IPC QSG GFK-2784J Power On/Off Switch and Status Indicator Operation Normal Operation Action † Press and hold the button for at least ½ second. If powering up from a no-power state, the ring LED blinks blue while the IPC is booting and is solid green Power up the IPC when the IPC is up and running.
-
Page 8: Contact Information
+ 86-21-3217-4826 (India, Indonesia, and Pakistan) (China) Support.cn.ip@ge.com Technical Support Email support.jp.ip@ge.com (Japan) (remaining Asia customers) support.in.ip@ge.com customercare.apo.ip@ge.com Customer Care Email customercare.cn.ip@ge.com (China) GE’s Automation & Controls Americas: 1-800-433-2682 or 1-434-978-5100 Global regional phone numbers are available at www.ge-ip.com GFK-2784J...
