5 Resources

Chapter Scope

5.1 Programmable devices

5.1.1 SMBUS DEVICES

Device Address
PI6C20800S 1101 110x
DB106 1101 010x
LM29245 1001 100x
24C08 1010 000x
LM95245 0101 001x

Table 16: SMBus Devices

Device Address
24c512 1010 000x
24c64 1010 111x

Table 17: I2C Bus device

5.2 ETHERNET

The Ethernet controllers provide internal configuration EEPROMs which also contains the MAC address.
PACSystems RXi Box IPC-XP Hardware Reference Manual
Internal
This chapter lists the hardware and firmware resources of the CEC04 carrier and the
bCOM6 module.
Function
PCIe Clock Buffer on CEC04
PCIe Clock Buffer on CEC02 (RXM1x2)
Temperature sensor on bC6L14 (via EC controller)
SPD on bC6L14
Temperature sensor on CEC04
Function
Factory EEprom of bC6L14
Factory EEprom of CEC02/CEC04
GFK-2990 53
