Framing Diagrams For Systems With Sump At The End - Chore-Time Turbo-Cool Installation & Operator's Instruction Manual

6" Recirculating Evaporative CoolingFraming Information
Option 1
22
20
12
20
16
Item Description
1 Curtain
2 7.5'' [191 mm] Minimum Clearance
3 14-1/2'' [368 mm] Minimum Sump Clearance
4 30'' - 36'' [762 - 914 mm] Walkway
5 6'' [152 mm] Minimum Clearance
6 2 x 6'' [38 x 140 mm] Top Stringer
7 Wall Studs
8 Pad Height less 2'' [51 mm]
9 End Framing
10 Width of Pad Bank
11 2 x 6'' [38 x 140 mm] Bottom Stringer
MV1669U

Framing Diagrams for Systems with Sump at the End

1
19
2
3
18
4
6
15
14
13
11
9
Figure 2.Framing overview diagram (Sump at either end)
Option 2
21
6
10
11
Item Description
12 Pad Height plus 2'' [51 mm]
13 1-1/4'' [32 mm]
14 Bottom Stringer Chalk-Line
15 Top Stringer Chalk-Line
16 19'' [432 mm] for Sump Assembly
17 6'' [152 mm] for Trough End Insert
18 7-1/2'' [191 mm]
19 3'' [76 mm]
20 2 x 6 Sump Back Support
21 Pad Height plus 20" Min. Clearance
22 Minimum Trough Clearance 9-1/4" [23.5 mm]
19
1
3
18
5
7
8
9
17
Mv1669-006 04/01
2
21
9
