Parts Lists and Kits6" Recirculating Evaporative Cooling
13
5
6
10
7
14
15
16
MV1669-055 4/06
Item
Description
1
RH Lower End Panel
2
LH Lower End Panel
3
RH Upper End Panel
4
LH Upper End Panel
5
Insert, TurboCool w/5" Hole
6
2x2x1.5 PVC Tee
7
1.5 PVC Ball Valve
8
4" Pipe to Tank Gasket
9
Trough Insert
10
1/8 Round Rubber Trim
11
4" PVC 90° Elbow
34
90° Around the Corner Kit (50464)
21
11
5
9
Part No.
46555-1
46555-2
46556-1
46556-2
46909
41427
44039
46061
46309
46310-1
46583
4
20
18
8
2
12
19 *
*
17
Item
Description
12
Clamp Strap
13
End Panel Support
14
Bolt, 5/16-18 x 4-1/2
15
Insert Washer
16
Nut, 5/16-18 Special
17
1/4 x 1-1/2 Lag Screw
18
1 x .275 SS Washer
19
#10-16 x .5 HH SS Screw
20
2" PVC 90° Elbow
21
2" x 40" PVC Pipe
22
4" x 40" PVC Pipe (Trough Connector)
3
22
1
19
19
19
17
Part No.
46100
44391
52607
52609
52606
41561
2955-52
38613
50465
50484
40472-4
MV1669U
