APPENDIX B: PINOUTS

RJ-45 DATA PORT PINOUT

The following table lists the pin configuration
for the RJ-45 Data connector.
Pin Signal Name
1000M
1 TXD1+
2
TXD1-
3
RXD2+
4
D3+
5
D3-
6 RXD2-
7
D4+
8 D4-
NOTE: The MDI/MDIX function will automatically adjust the direction of these signals to match the connected
unit when running 10/100Base-T. 1000Base-T will use all 4 pairs in full duplex mode.

RS-232 SERIAL CONSOLE PORT

The following table lists the pin configuration for the RS-232 3-pin mini jack
mating connector for the console serial port.
Pin
Tip
Ring
Sleeve
Signal Direction
10/100M
Out*
Out*
In*
In*
DB9-F Pin#
2
3
5
60
iMcV-Giga-FiberLinX-III
Signal Name
Transmit
Receive
Return
Pin 1
Direction
Out of Unit
In to Unit
Return
