PASSWORD PROTECTION FOR SERIAL PORT CONNECTIONS
Password/username is not offered for the serial port by default. This allows the
end user to quickly access the device for basic configuration capability.
Password protection is provided for the serial configuration process by pressing
P on the main configuration screen. Enter a password (keeping in mind that
passwords are case-sensitive and must not exceed eight characters or include
spaces) and press Enter. This password will be requested whenever logging on.
To remove password protection, select P and, instead of entering a password,
press Enter.
Passwords have the following requirements:
• Password must be between 1 and 8 characters long
• Password consists of a combination of any ASCII characters except spaces
• Passwords are case sensitive
Passwords make the management of the devices secure; but password lists
must be stored and maintained.
ASSIGNING TRAP DESTINATIONS
Traps are sent by the manageable device to a management PC when a certain event
takes place. To enter a trap destination, press T. When prompted, enter a New IP
Address prompt, enter the appropriate IP address of the destination device and press
Enter. Then, type the name of the community string (that the destination device has
been configured to accept) and press Enter. Select whether the trap is for SNMP
version 1 or 2c and press Enter. This function enables ALL of the device traps.
Supported traps include: Link Down, Link Up, Last Gasp.
REMOVING TRAP DESTINATIONS
To remove all trap destinations, press K. Press Y to continue to confirm or N to abort
and remove all trap destinations. Press Enter to finish.
This function will delete all trap destinations. To selectively delete trap destinations or
to disable/enable Traps, use iView
another Trap destination, repeat the steps listed above.
iMcV-Giga-FiberLinX-III
2 (iConfig view) to configure the device. To enter
