HOST/REMOTE AND STANDALONE UNITS

The iMcV-Giga-FiberLinX-III can be used as a Host, Remote, or Standalone unit.
Refer to the Application Examples section for examples.
When two iMcV-Giga-FiberLinX-III units are used as a pair, configure one as a
Host unit (DIP Switch 8 = ON) and the other as a Remote unit (DIP Switch 7 =
ON). As a host unit, the iMcV-Giga-FiberLinX-III requests management
information from the attached remote unit. It then displays that information, along
with its own, when queried by SNMP. As a Remote unit, the iMcV-Giga-
FiberLinX-III responds to requests for management information from an attached
Host unit.
The iMcV-Giga-FiberLinX-III default configuration is as a Standalone unit (DIP
Switches 7 and 8 = OFF).

LOSPD

When LoSPD is set to ON, it will force the SFP mode to run at 100Mbps. If it is
set to OFF, the SFP will run at the highest useable speed determined by the SFP
itself.

MINI-SERIAL PORT

A console port, located on the front faceplate of the module, allows the customer
to use a local RS-232 serial interface for management. A special mini-jack to
DB9-F cable is provided with the product for direct connection to a PC serial port.
Function
Management on EXT MGMT port
Management on DATA port
Management on OPTICS or UPLINK port
Factory use – Do not change
Factory use – Do not change
LoSPD SFP
If the model is 1x9, LoSPD is not functional,
Remote Module
Host Module
iMcV-Giga-FiberLinX-III
8
Default Setting
ON
OFF
OFF
---
---
OFF
OFF
OFF
