The Port screen contains the following commands:
Port
Enable
Admin
Status
Port
Speed
Ctrl
Advertise
Ctrl
Advertise
FlowCtrl
Force
FlowCtrl
LFPT
from
Unit
FlowCtrl
Enable/Disable the port. (Select Enable to enable the port.)
Set Administration status. (Select UP to enable/disable
management through the port.)
Both settings must be enabled to enable the port.
Set the port manually or for Auto Negotiation for Twisted Pair
ports. By default, the setting is AN. A Force mode can be selected
for both speed and duplex at 10, 100 or 1000Mbps.
This is the Selective Advertising feature. Selective Advertising,
when used in combination with Auto Negotiation, advertises the
configured speed and duplex mode for the twisted pair ports. Auto
Negotiation must be enabled for Selective Advertising.
This enable/disable feature is the selection for Advertising Flow
Control. Choose this option to change based on the link partner's
capability. By default, it is enabled as Advertise Flow.
This is the selection for Force Flow Control; choose this if enabling
Flow Control. You can select Force and select it to automatically
negotiate based on the link partner's capability.
This is the Link Fault Pass Through (LFPT) diagnostic function. By
default, this is disabled. You can choose any two ports to
configure LFPT in order for the device to report a failure to one
port if a fault occurs on another port.
This is the selection for enabling/disabling global flow control.
Once this is set to enabled, you can select the flow control settings
for each port as listed in the above list.
