5
Loopback Test - Optional
• Set DIP switches 1, 3, 4 to ON.
• Set DIP switch 2 to OFF.
• Use HyperTerminal or another terminal
program to confirm passage of data
through converter.
6
Check LEDs
When everything is installed and connected,
the LEDs will blink to let you know that data traffic is
passing through the converter
7
Troubleshooting
What baud rates can be used?
Baud rates up to 921.6 Kbps.
Which USB cables can I use?
A 0.9 meters (3 ft) cable is included. Other
lengths can be purchased separately. The
maximum range for USB is 4.6 meters (15 ft).
If you need to go farther than 4.6 meters (15 ft),
Advantech B+B also sells USB extenders.
Can I get another terminal block
for Model BB-USOPTL4DR-2?
Yes. The order number is BB-TBKT2.
Document Number: 20BB710-11250-00_r3_BB-USOPTL4DR-2_2320qsg
Recommended Accessories
4-Port USB Hub
Model# BB-UHR204
www.advantech.com
707 Dayton Road | PO Box 1040 | Ottawa, IL 61350 USA
Phone: 1 (815) 433-5100 | Fax: 1 (815) 433-5109
www.advantech.com | E-mail: support@advantech-bb.com
QUICK START
GUIDE
Model BB-USOPTL4DR-2
USB to RS-422/485
Isolated Converter
Before you begin, be
sure you have the following:
+ BB-USOPTL4DR-2 Converter
+ USB Cable
+ CD ROM with Drivers
www.advantech.com
Fast and easy on the web:
