PORT INTERFACES

Every iMcV-Giga-FiberLinX-III includes the following ports:
• A 10/100/1000 twisted pair (RJ-45) port (EXT MGMT) for management
One of the following ports:
• One fixed 1000 Mbps Fiber port
OR
• SFP port capable of receiving a Gigabit or 100Mbps fiber optic SFP
module, or a Gigabit twisted pair (RJ-45) SFP module
DATA port:
• 10/100/1000 twisted pair (RJ-45) port

MANAGEMENT

Although the iMcV-Giga-FiberLinX-III provides a twisted-pair port solely for
management (EXT MGMT), the iMcV-Giga-FiberLinX-III can be configured to
accept IP-based management traffic from any of its three ports. Enable
management on more than one port, or disable management on all of the ports,
as desired. These switches limit only IP-based management. Host-to-Remote
management is IP-less and never blocked from the fiber port. Serial port
management of the unit is available via the console port located at the top of the
module using a mini jack adapter.
In addition to defining which ports are used to manage the iMcV-Giga-FiberLinX-
III units, the management DIP switch settings also define what ports the flow of
the Network Provider's Management Domain traffic can take through the unit.
See Application Examples for information regarding Management Domain.
DIP Switch 1 = ON for management on the EXT MGMT port
DIP Switch 2 = ON for management on the DATA port
DIP Switch 3 = ON for management on the OPTICS or UPLINK port
iMcV-Giga-FiberLinX-III
