ISHIDA UNI-7 Service Manual

Hide thumbs Also See for UNI-7:
Table of Contents

Advertisement

Quick Links

See also: User Manual
IMPORTANT
• Read this manual thoroughly, and do not perform
installation, operation, maintenance, or inspection
unless you fully understand all of the contents.
• Keep this manual in a safe place where you can refer
to it easily while installing, operating, and carrying out
maintenance or inspections.
UNI-7
Service Manual
RS-61004-11

Advertisement

Table of Contents
loading

Related Manuals for ISHIDA UNI-7

Summary of Contents for ISHIDA UNI-7

  • Page 1 UNI-7 Service Manual IMPORTANT • Read this manual thoroughly, and do not perform installation, operation, maintenance, or inspection unless you fully understand all of the contents. • Keep this manual in a safe place where you can refer to it easily while installing, operating, and carrying out maintenance or inspections.
  • Page 2 © ISHIDA Co., Ltd. 2008 All rights are reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means mechanical, electronic, photocopying, recording, or otherwise without prior written permission of ISHIDA.
  • Page 3 ISHIDA is not liable for any damage, loss or injury that results from incorrect operation, insufficient caution, unauthorized modifications to the machine, or failure to follow the instructions contained in this manual.
  • Page 4 Additionally, there may be significant property damage. Indicates a potentially hazardous situation where, if not avoided, may result in minor or moderate injury or in property damage. Indicates reference information for operation. Indicates the referred page for operation. UNI-7 Service Manual...
  • Page 5 Dropping the machine may result in injury or cause the machine to break down. • Do not drop the cassette. Dropping the cassette may result in injury or cause the cassette to break down. UNI-7 Service Manual...
  • Page 6 • Do not press the touch panel with an edged thing. Doing so may scratch the panel and cause the machine to break down. • Do not dispose of batteries with normal household waste. Please obey your local regulations when disposing of used batteries. UNI-7 Service Manual...
  • Page 7 Do not try to induce vomiting. Do not give the victim anything to drink, and do not rinse the mouth. If vomiting occurs naturally, have the victim lean forward to reduce risk of aspiration. Keep the victim warm and seek medical attention. UNI-7 Service Manual...

  • Page 8: Table Of Contents

    ELECTRICAL SIGNALS MAIN BOARD (PK-260).................. 4-1 KEY/LCD BOARD (PK-261) ................4-7 LCD BOARD (PK-263) ................... 4-9 WIRELESS LAN BOARD (PK-265).............. 4-10 SELF-SERVICE MASTER BOARD (PK-266) ..........4-11 SELF-SERVICE MASTER BOARD (PK-267) ..........4-12 THERMAL BOARD (PK-268) ............... 4-13 UNI-7 Service Manual...
  • Page 9 HANGING TYPE ................... 5-28 5.6.1 HANGING POLE..................5-28 5.6.2 MAIN BOARD .................... 5-30 5.6.3 OPERATION PANEL ................. 5-31 5.6.4 FRONT & REAR STAINLESS-STEEL HOUSINGS ........5-32 5.6.5 POWER SUPPLY UNIT................5-35 5.6.6 LOAD CELL BOARD ................. 5-36 UNI-7 Service Manual...
  • Page 10 KEY CHECK ....................8-3 PROGRAM NUMBER ..................8-5 MEMORY CLEAR ................... 8-6 PRINTER ADJUSTMENT ................8-8 CALIBRATION....................8-16 DOWNLOADING................... 8-19 OPTION CHECK ................... 8-23 DISPLAY CAPTURE..................8-25 8.10 MODEL SETTING ..................8-26 Chapter 9 ERROR SCREENS viii UNI-7 Service Manual...
  • Page 11 TABLE OF CONTENTS Appendix TEXT EDITING OPERATION PANEL AND KEY FUNCTIONS ..........A-1 NORMAL CHARACTER REGISTRATION .............A-3 SPECIAL CHARACTER REGISTRATION .............A-6 LINE DELETION .....................A-8 CHARACTER DELETION................A-9 CHARACTER BACKSPACING ..............A-11 UNI-7 Service Manual...
  • Page 12 TABLE OF CONTENTS UNI-7 Service Manual...

  • Page 13: Chapter 1 Basic Information

    Chapter 1 BASIC INFORMATION BASIC INFORMATION OUTER DIMENSIONS FOR EACH TYPE 1.1.1 OUTER DIMENSIONS FOR BENCH TYPE Bench Type UNI-7 Service Manual...

  • Page 14: Outer Dimensions For Pole Type

    Chapter 1 BASIC INFORMATION 1.1.2 OUTER DIMENSIONS FOR POLE TYPE Pole Type UNI-7 Service Manual...

  • Page 15: Outer Dimensions For Bakery Type

    Chapter 1 BASIC INFORMATION 1.1.3 OUTER DIMENSIONS FOR BAKERY TYPE Bakery Type UNI-7 Service Manual...

  • Page 16: Outer Dimensions For Self-Service Type

    Chapter 1 BASIC INFORMATION 1.1.4 OUTER DIMENSIONS FOR SELF-SERVICE TYPE Self-service Type UNI-7 Service Manual...

  • Page 17: Outer Dimensions For Elevated Type

    Chapter 1 BASIC INFORMATION 1.1.5 OUTER DIMENSIONS FOR ELEVATED TYPE Elevated Type UNI-7 Service Manual...

  • Page 18: Outer Dimensions For Hanging Type

    Chapter 1 BASIC INFORMATION 1.1.6 OUTER DIMENSIONS FOR HANGING TYPE Hanging Type UNI-7 Service Manual...

  • Page 19: Specifications

    Label size Label width: 30mm to 60mm Label length: 20mm to 150mm Number of label cassettes 7 cassettes Input/Output LAN 1 channel USB 1 channel CF 1 channel Drawer 2 channels Program store medium Flash ROM (32M bytes) UNI-7 Service Manual...

  • Page 20: Installation

    To avoid personal injury and shock, do not open or remove any covers or enclosures of the machine unless specified in the manual. • Do not perform unspecified maintenance. For your personal safety, do not perform any maintenance procedures which are not specified in the manual. UNI-7 Service Manual...

  • Page 21: Precautions For Installation

    • Places exposed to direct cold sunlight fluctuations • Places where water or other air from air conditioners or liquids are easily spilled on the refrigerators • Places where the floor or machine foundation is unstable UNI-7 Service Manual...
  • Page 22 Chapter 1 BASIC INFORMATION 1-10 UNI-7 Service Manual...

  • Page 23: Chapter 2 Assembly Drawings

    Chapter 2 ASSEMBLY DRAWINGS ASSEMBLY DRAWINGS BENCH TYPE UNI-7 Service Manual...
  • Page 24 BRACKET LEVEL BRACKET POWER LEVEL UNIT FRAME LEVEL HARNESS 'C2' POWER LENS LEVEL KEY SHEET BRACKET TORQUE HINGE NAME PLATE SPEC HINGE L STICKER 'M' HINGE R STICKER LOCATION OUTPUT ACCESSORY CLAMP USB GASKET CASE REAR CONTROL UNI-7 Service Manual...

  • Page 25: Pole Type

    Chapter 2 ASSEMBLY DRAWINGS POLE TYPE UNI-7 Service Manual...
  • Page 26 HINGE L STICKER LOCATION OUTPUT HINGE R USB GASKET ACCESSORY CLAMP SHEET DOUBLE TAPE CASE REAR CONTROL VIBRATION MOTOR PK-261 BRACKET LCD ACCESSORY PCB SUPPORT BRACKET LCD LCD TP CASE FRONT CONTROL MEMBRANE KEYBOARD ASSEMBLY CLEAR SHEET UNI-7 Service Manual...

  • Page 27: Bakery Type

    Chapter 2 ASSEMBLY DRAWINGS BAKERY TYPE UNI-7 Service Manual...
  • Page 28 HINGE R INSULATION SHEET HINGE L ACCESSORY PWB GUIDE SPA FERRITE CORE HARNESS S2 24V DC POWER EARTH CLAMP FERRITE CORE CASE REAR CONTROLL DOUBLE TAPE PWB PK-261* FERRITE CORE HARNESS S2 FRONT LCD BRACKET LCD PCB SUPPORT UNI-7 Service Manual...

  • Page 29: Self-Service Type

    FOOT ADJUST PWB PK-267* BUMPON FRAME KEY UNIT VIBRATOR ASSEMBLY CASE REAR KEY UNIT CABLE CLAMP CASE REAR KEY UNIT HARNESS C2 SERIAL CAP RECTANGLE NAME PLATE SPEC FRAME KEY UNIT-L BRACKET KEY UNIT FRAME KEY UNIT-R UNI-7 Service Manual...

  • Page 30: Elevated Single Printer Type

    Chapter 2 ASSEMBLY DRAWINGS ELEVATED SINGLE PRINTER TYPE UNI-7 Service Manual...
  • Page 31 HARNESS 'C2' POWER ASS'Y NAME PLATE SPEC GASKET 20mm LEVEL LENS STICKER LOCATION OUTPUT FERRITE CORE CASE MAIN UPPER FERRITE CORE COVER PRINTER UPPER FERRITE CORE BLOCK B HINGE PLATTER HARNESS S2 LAN RUBBER PLATTER SUPPORT HARNESS S2 5V POWER UNI-7 Service Manual...

  • Page 32: Elevated Dual Printer Type

    Chapter 2 ASSEMBLY DRAWINGS ELEVATED DUAL PRINTER TYPE 2-10 UNI-7 Service Manual...
  • Page 33 FRRITE CORE BLOCK B HINGE PLATTER FRRITE CORE RUBBER PLATTER SUPPORT FRRITE CORE PLATTER SUPPORT HARNESS 'S 2' 24V DC BRACKET PLATTER SUPPORT INSULATION SHEET LOADCELL HARNESS S2 LAN BRACKET LOADCELL HARNESS S2 5V POWER COVER HARNESS UNI-7 Service Manual 2-11...
  • Page 34 Chapter 2 ASSEMBLY DRAWINGS 2-12 UNI-7 Service Manual...

  • Page 35: Chapter 3 Block Diagrams

    Chapter 3 BLOCK DIAGRAMS BLOCK DIAGRAMS BLOCK DIAGRAM (BENCH/POLE TYPE) UNI-7 Service Manual...

  • Page 36: Block Diagram (Bakery Type)

    Chapter 3 BLOCK DIAGRAMS BLOCK DIAGRAM (BAKERY TYPE) UNI-7 Service Manual...

  • Page 37: Block Diagram (Self-Service Type)

    Chapter 3 BLOCK DIAGRAMS BLOCK DIAGRAM (SELF-SERVICE TYPE) UNI-7 Service Manual...

  • Page 38: Block Diagram (Hanging Type)

    Chapter 3 BLOCK DIAGRAMS BLOCK DIAGRAM (HANGING TYPE) UNI-7 Service Manual...

  • Page 39: Block Diagram (Elevated Type)

    Chapter 3 BLOCK DIAGRAMS BLOCK DIAGRAM (ELEVATED TYPE) Single Printer UNI-7 Service Manual...
  • Page 40 Chapter 3 BLOCK DIAGRAMS Dual Printer UNI-7 Service Manual...

  • Page 41: Chapter 4 Electrical Signals

    28,29 Light control signal for LCD backlight ← External buzzer signal → Vibration signal → 32,33 DC+5V 34 - 39 Membrane key control signal ←→ Signal Name Direction Opposite Side 1 - 14 Debug signal ←→ Unused UNI-7 Service Manual...
  • Page 42 AC power supply for LCD PK-263(XJ1) DC-10V power supply for LCD DC+15V power supply for LCD DC+15V power supply for LCD backlight 27,28 Light control signal for LCD backlight → 24,25 DC+5V Signal Name Direction Opposite Side P-999 DC+12V UNI-7 Service Manual...
  • Page 43 Opposite Side 1 - 6 For CPLD writing ←→ Unused XJ10 Signal Name Direction Opposite Side DC+5V Unused XJ11 Signal Name Direction Opposite Side DC+5V → Unused → ← ← XJ12 Signal Name Direction Opposite Side DC+5V Unused UNI-7 Service Manual...
  • Page 44 Signal Name Direction Opposite Side Peel sensor DC+5V Peel sensor LED_GND Peel sensor LED_VCC Peel sensor ← SENS_IN Peel sensor Peel sensor Label sensor Label sensor DC+5V Label sensor LED_GND Label sensor LED_VCC Label sensor SENS_IN Label sensor UNI-7 Service Manual...
  • Page 45 Cassette 2 LED Cassette 2 SENS_IN ← Cassette 3 LED Cassette 3 SENS_IN ← XJ22 Signal Name Direction Opposite Side 1,2,3 DC+24V main power supply Switching power supply 4,5,6 XJ23 Signal Name Direction Opposite Side DC+24V Unused UNI-7 Service Manual...
  • Page 46 Chapter 4 ELECTRICAL SIGNALS XJ24 Signal Name Direction Opposite Side 13,38 DC+3.3V 1,50 Others CF control signal ←→ XJ25 Signal Name Direction Opposite Side USB_VBUS USB_D+ ←→ USB_D- ←→ USB_GND NONE VBUS ←→ ←→ UNI-7 Service Manual...

  • Page 47: Key/Lcd Board (Pk-261)

    DC+15V power supply LCD backlight 28,29 Light control signal for LCD backlight ← External buzzer signal → Vibration signal → 32,33 DC+5V 34 - 39 Membrane key control signal ←→ Signal Name Direction Opposite Side Unused → DC+5V UNI-7 Service Manual...
  • Page 48 Key scanning 1,2,3,4, → 5,6,7,8 KS0 - KS7 9,10,11,12, Membrane key Key data 13,14,15,16, ← KD0 - KD10 17,18,19 Unused Signal Name Direction Opposite Side DC+5V Unused XJ10,11 Signal Name Direction Opposite Side DC+5V for vibration Vibration unit UNI-7 Service Manual...

  • Page 49: Lcd Board (Pk-263)

    1,21 DC+5V power supply for LCD LCD GND 10,11 AC power supply for LCD DC-10V power supply for LCD DC+15V power supply for LCD Others LCD control signal ←→ Signal Name Direction Opposite Side DC+5V LCD backlight UNI-7 Service Manual...

  • Page 50: Wireless Lan Board (Pk-265)

    Chapter 4 ELECTRICAL SIGNALS WIRELESS LAN BOARD (PK-265) Signal Name Direction Opposite Side DC+5V PK-260 XJ12 Signal Name Direction Opposite Side → → ← ← PK-260 XJ3 LEDR LEDL 4,7,13,14 9,12 DC+3.3V 4-10 UNI-7 Service Manual...

  • Page 51: Self-Service Master Board (Pk-266)

    3,4,5,6 Membrane key control signal ←→ Signal Name Direction Opposite Side Key scan 1,2,3,4,5,6 → KS0 - KS5 Membrane key Key data 7,8,9,10,11,12 ← KD0 - KD5 XJ6/XJ7 Signal Name Direction Opposite Side DC+5V Vibration unit UNI-7 Service Manual 4-11...

  • Page 52: Self-Service Master Board (Pk-267)

    SELF-SERVICE MASTER BOARD (PK-267) Signal Name Direction Opposite Side DC+5V PK-266 XJ3/XJ4 3,4,5,6 Membrane key control signal ←→ Signal Name Direction Opposite Side Key scan 1,2,3,4,5,6 → KS0 - 5 Membrane key Key data 7,8,9,10,11,12 ← KD0 - 5 4-12 UNI-7 Service Manual...

  • Page 53: Thermal Board (Pk-268)

    PK-269 XJ1 TH (Thermistor input signal) ← MOTOR_A → MOTOR_B → MOTER_A# → MOTER_B# → CUTS (Cutter sensor) ← CUTB (Cutter motor) → CUTA (Cutter motor) → Signal Name Direction Opposite Side CD+24V DC+24V DC+24V PK-260 XJ23 UNI-7 Service Manual 4-13...
  • Page 54 Opposite Side D_Vbus (Port4) D_Vbus (Port3) D_D- (Port4) ←→ D_D- (Port3) ←→ D_D+ (Port4) ←→ Unused D_D+ (Port3) ←→ D_GND (Port4) D_GND (Port3) D_GND (Port3) Signal Name Direction Opposite Side Unused DC+5V 3,4,5,6,7,8 FROM write signal ←→ 4-14 UNI-7 Service Manual...

  • Page 55: Thermal Connector Board (Pk-268)

    Opposite Side PS (Paper sensor receiver) ← VPS (Paper sensor emmiter) → 3,4,11,12, 13,14,25 HS (Platen position sensor) ← Printer unit 6,19,20 DC+24V (Head drive power supply) 7,8,9,16, Thermal head control signal ←→ 17,18 DC+5V － UNI-7 Service Manual 4-15...
  • Page 56 Chapter 4 ELECTRICAL SIGNALS Signal Name Direction Opposite Side TH (Thermistor input signal) ← MOTOR_A → MOTOR_B → MOTER_A# → MOTER_B# → 4-16 UNI-7 Service Manual...

  • Page 57: Scale Board (Pk-999)

    Chapter 4 ELECTRICAL SIGNALS SCALE BOARD (PK-999) Signal Name Direction Opposite Side DC+12V ･PK-260 Not connected Not connected Not connected UNI-7 Service Manual 4-17...
  • Page 58 Chapter 4 ELECTRICAL SIGNALS 4-18 UNI-7 Service Manual...

  • Page 59: Chapter 5 Machine Disassembly

    Remove the five screws (blue), two tapping Remove the upper case. screws (red), and one TP screw (green). Upper case Weigh platter holder * Reverse this procedure for assembly. UNI-7 Service Manual...

  • Page 60: Weigh Platter Holder

    (Refer to section 5.1.1) platter holder. Weigh platter holder Motor STP-29D1026 Remove the weigh platter holder. Motor STP-29D1026 Power supply ZWS150PAF-24/J AD board P-999 (in the die-cast) Load cell CLC-25N Main board PK-260 * Reverse this procedure for assembly. UNI-7 Service Manual...

  • Page 61: Main Board

    Chapter 5 MACHINE DISASSEMBLY 5.1.3 MAIN BOARD Unplug all harnesses connected to the main Remove the three screws fixing the main board. board. Squeeze the two spacers to remove the main board. Reverse this procedure for assembly. UNI-7 Service Manual...

  • Page 62: Operation Panel

    Bottom case Unplug all harnesses and remove the fixing Unplug the harnesses and peel off the screws to detach the touch panel LCD with vibrator attached with the double-faced tape. the bracket. Display/ Key control board PK-261 Vibrator UNI-7 Service Manual...
  • Page 63 Chapter 5 MACHINE DISASSEMBLY TFT touch panel LCD Membrane keys * Reverse this procedure for assembly. UNI-7 Service Manual...

  • Page 64: Customer Display

    Remove the weigh platter holder and unplug Detach the customer display unit. the harness connected with the main board. Detach the display control board and TFT LCD. TFT LCD Display control board AT070TN07 PK-263 * Reverse this procedure for assembly. UNI-7 Service Manual...

  • Page 65: Label Sensor

    Unplug the harness. label sensor unit so as not to drop or lose the inserted collars. Remove the screw fixing the bracket. This photo shows the breakdown of the sensor unit. * Reverse this procedure for assembly. UNI-7 Service Manual...

  • Page 66: Peel Sensor

    * Reverse this procedure for assembly. 5.1.8 CASSETTE SENSOR Pull out the cassette unit from the main unit. Remove the two screws and unplug the harness to remove the cassette sensor. Cassette sensor * Reverse this procedure for assembly. UNI-7 Service Manual...

  • Page 67: Thermal Head Unit

    Squeeze the springs by holding up the head unit and pull out the thermal head unit. Unplug the connector and remove the two This photo shows the breakdown of the screws. thermal head unit. * Reverse this procedure for assembly. UNI-7 Service Manual...

  • Page 68: Load Cell & A/D Board

    Remove the two hexagon socket head Remove the two screws to remove the bolts at the other end and detach the load die-cast bracket. cell unit. Unplug the harnesses and squeeze the two spacers (green) to detach the AD board. 5-10 UNI-7 Service Manual...

  • Page 69: Power Supply Unit

    Disengage the five hooks at the bottom of Detach the customer display unit and remove the machine using a slotted screwdriver. the two screws fixing the power supply unit. Remove the power supply unit. * Reverse this procedure for assembly. UNI-7 Service Manual 5-11...

  • Page 70: Motor Unit

    Remove the three screws fixing the side Detach the side cover. cover. Remove the screw fixing the cable fastener. Remove the two screws fixing the plate. Remove the plate. Remove the motor. Unplug the connector. Remove the timing belt from the pulley. 5-12 UNI-7 Service Manual...
  • Page 71 Chapter 5 MACHINE DISASSEMBLY Remove the motor unit. Reverse this procedure for assembly. UNI-7 Service Manual 5-13...

  • Page 72: Wireless Lan Unit

    Turn to remove the antenna. and the LAN cable are unplugged. When removing the LAN board, remove This photo shows the constituent parts for the two screws. the wireless LAN unit. * Reverse this procedure for assembly. 5-14 UNI-7 Service Manual...

  • Page 73: Pole Type

    Rear case Unplug the display harness connector on the main board to remove the pole unit. * Reverse this procedure for assembly. UNI-7 Service Manual 5-15...

  • Page 74: Customer Display Unit

    Detach the front panel of the customer case of the customer display unit. display unit. Unplug the connector. Remove the two screws and unplug the two harnesses. Display control board PK-263 Remove the display control board. * Reverse this procedure for assembly. 5-16 UNI-7 Service Manual...

  • Page 75: Bakery Type

    Raise the operation panel and remove the remove the top cover. screw fixing the hinge cover. Make the operation panel angle about 45° Remove the six screws fixing the upper case. and pull out the hinge cover. UNI-7 Service Manual 5-17...
  • Page 76 Chapter 5 MACHINE DISASSEMBLY Lift to remove the upper case. * Reverse this procedure for assembly. 5-18 UNI-7 Service Manual...

  • Page 77: Self-Service Type

    Remove the screw fixing the cable clamp and self-service panel unit so that you can work the grounding terminal. from the bottom. Remove the two screws fixing the blind Detach the blind plate and unplug the plate. connector. Blind plate UNI-7 Service Manual 5-19...
  • Page 78 Chapter 5 MACHINE DISASSEMBLY Remove the two screws fixing the cable clamps. Separate the self-service panel unit from the machine. Self-service panel unit 5-20 UNI-7 Service Manual...

  • Page 79: Panel Control Board

    5.4.2 PANEL CONTROL BOARD Lift to disengage the two hooked places and detach the blind cover of the self-service panel unit.. Blind cover Remove the four screws to detach the rear cover. Rear cover Panel control board UNI-7 Service Manual 5-21...

  • Page 80: Elevated Type

    Remove the two screws located at the bottom of the operation panel unit. customer display side. R emove the screw located on the bottom of Slide the roll holder release lever in the the operation panel unit. arrow direction. Operation panel 5-22 UNI-7 Service Manual...
  • Page 81 Remove the screw located inside of the Detach the operation panel. operation panel unit. This photo shows the rear side of the This photo shows the inside of the operation operation panel. panel unit and the rear side of the operation panel. UNI-7 Service Manual 5-23...

  • Page 82: Operation Panel Unit (For Single Printer)

    R emove the screw located on the bottom of , peel off the blind plate. the operation panel unit. Operation panel Remove the two screws fixing the roll Pull out the holder. holder. Remove the screw fixing the operation Detach the operation panel. panel. 5-24 UNI-7 Service Manual...

  • Page 83: Printer Unit (For Dual Printer)

    Make sure that the roll holder is removed from the operation panel unit. (Refer to section 5.5.1) Also make sure that the operation panel unit is disassembled. (Refer to section 5.5.1) Printer Remove the two screws fixing the printer Detach the printer unit. unit. UNI-7 Service Manual 5-25...

  • Page 84: Customer Display Unit

    Remove the two screws fixing the customer Remove the two screws (blue) and loosen display unit. the other two screws (green). Roll holder Detach the customer display unit and Open the customer display unit. remove the four fixing screws. 5-26 UNI-7 Service Manual...

  • Page 85: Elevated Unit

    Chapter 5 OVERVIEW 5.5.5 ELEVATED UNIT Turn to remove the level adjusting foot. Remove the three screws fixing the pole bottom cover. Remove the three hexagon socket head bolts fixing the elevated unit. UNI-7 Service Manual 5-27...

  • Page 86: Hanging Type

    Chapter 5 MACHINE DISASSEMBLY HANGING TYPE 5.6.1 HANGING POLE Disengage the joint section to remove the weigh platter unit. Weigh platter unit Remove the weigh platter unit. Remove the two screws fixing the hanging pole cover. Hanging pole cover 5-28 UNI-7 Service Manual...
  • Page 87 Remove the bolts fixing the pole from the ceiling and the pole from the main unit. These photos show the front-side and rear-side views of the main unit. Front-Side View Rear-Side View * Reverse this procedure for assembly. UNI-7 Service Manual 5-29...

  • Page 88: Main Board

    Raise the operation panel and remove the Remove the front cover of the main unit. four fixing screws. Front cover Unplug all harnesses connected with the main board and remove the five fixing screws. * Reverse this procedure for assembly. 5-30 UNI-7 Service Manual...

  • Page 89: Operation Panel

    Raise the operation panel and remove the two upper screws and loosen the two lower screws. Operation panel Unplug the keyboard harness from the main board and remove the screw for the cable clamp. Remove the operation panel from the main unit. * Reverse this procedure for assembly. UNI-7 Service Manual 5-31...

  • Page 90: Front & Rear Stainless-Steel Housings

    Make sure that the operation panel is removed. (Refer to section 5.6.3) Front cover Remove the cassette unit from the main unit Remove the printer frame. and also remove the printer cover. Printer cover Printer frame 5-32 UNI-7 Service Manual...
  • Page 91 Chapter 5 MACHINE DISASSEMBLY Remove the ten screws fixing both front and rear stainless-steel housings. Slide to remove both front and rear stainless-steel housings. Front housing Rear housing UNI-7 Service Manual 5-33...
  • Page 92 Unplug the harness connected with the display control board located inside of the rear housing. These photos show the front and rear views. Main board Printer unit Printer unit Power supply unit Motor unit * Reverse this procedure for assembly. 5-34 UNI-7 Service Manual...

  • Page 93: Power Supply Unit

    Slide to remove the rear case of the main unit. Rear case Unplug all harnesses connected with the power supply board and carefully remove the four fixing screws so as not to drop the collars behind. * Reverse this procedure for assembly. UNI-7 Service Manual 5-35...

  • Page 94: Load Cell Board

    Remove the six screws fixing the upper Detach the upper case and unplug the case. harness. Load Cell board housing Remove the three screws fixing the load cell board housing. * Reverse this procedure for assembly. 5-36 UNI-7 Service Manual...

  • Page 95: Motor Unit

    Chapter 5 MACHINE DISASSEMBLY 5.6.7 MOTOR UNIT Make sure that the rear stainless-steel case is removed. (Refer to section 5.6.4) Remove the power supply unit. (Refer to Remove the four fixing screws to detach the section 5.6.5) motor unit. UNI-7 Service Manual 5-37...
  • Page 96 Chapter 5 MACHINE DISASSEMBLY 5-38 UNI-7 Service Manual...

  • Page 97: Chapter 6 Mechanical Adjustment

    Chapter 6 MECHANICAL ADJUSTMENT MECHANICAL ADJUSTMENT FOUR CORNER LIMIT SPACE Adjust the limit spaces at four corners of the weigh platter holder to become the following values. (1) 2mm, (2) 2mm, (3) 2.5mm, (4) 3.2mm Weigh platter holder UNI-7 Service Manual...

  • Page 98: Cassette Magnet Position

    Magnet Loosen the two screws and move the magnet back and forth for adjustment. Be sure to tighten the screws after adjustment. Check that the cassette unit is securely fixed by the magnet. Magnet Bottom of cassette UNI-7 Service Manual...

  • Page 99: Gear Engagement

    Chapter 6 MECHANICAL ADJUSTMENT GEAR ENGAGEMENT Make sure that the weigh platter holder is removed. Loose the two screws to move the pulley to the appropriate position for better engagement. Be sure to tighten the screws after adjustment. UNI-7 Service Manual...

  • Page 100: Support Roller

    Chapter 6 MECHANICAL ADJUSTMENT SUPPORT ROLLER Remove the three screws fixing the side Remove the side cover. cover. Loosen the screw fixing the support roller. Be sure to tighten it after adjustment. UNI-7 Service Manual...

  • Page 101: Print Position

    This photo shows the position of the body. thermal head unit. Thermal head unit Loosen the two screws and move the thermal head unit back and forth and around for position adjustment. Be sure to tighten the screws after adjustment. UNI-7 Service Manual...

  • Page 102: Thermal Head Position

    62mm width, adjust the gap between the width, adjust the gap between the bracket bracket and the left end of the thermal and the left end of the thermal head to be head to be 2mm ±0.5mm. 3mm ±0.5mm. UNI-7 Service Manual...

  • Page 103: Chapter 7 Setup Mode

    Chapter 7 SETUP MODE SETUP MODE ENTERING SETUP MODE Press the [SETUP] button on the Menu Select screen. The Setup Menu screen appears. Press the [ ] button when changing pages. The next setup menu screen appears. UNI-7 Service Manual...
  • Page 104 Chapter 7 SETUP MODE Enter “495344” and press the [PLU] key on the key sheet to enter Service Mode. Hidden menus come up on the screen. Press the [ ] or [ ] button when changing the pages. UNI-7 Service Manual...

  • Page 105: Cassette Setting

    Press the [ ] or [ ] button to scroll the table on the screen up or down.. Press the [ ] or [ ] button to scroll the table on the screen to right or left. Press to select a desired cassette number field. EXAMPLE Select cassette number “3”. UNI-7 Service Manual...
  • Page 106 Chapter 7 SETUP MODE Press to select either “Format No.” or “Label Spec”. Press the [FORMAT EDIT] button. The Label Format (Basic) screen appears. Press the [EDIT] button. The following text edit screen appears. UNI-7 Service Manual...
  • Page 107 Enter a numeric value and press this field. LABEL NO. Enter a numeric value and press this field. UNIT NO. Enter a numeric value and press this field. Select a desired print unit data by using the [<] or [>] button. UNI-7 Service Manual...
  • Page 108 To move the designated area to a desired direction, press the [ ] [ ] [ ] [ ] buttons, or, enter desired numeric values and press the “X-Axis” and ”Y-Axis” fields. To display the Label Format (Unit) screen, press the [UNIT] tab. To change the pages, press the [ ] or [ ] button. UNI-7 Service Manual...
  • Page 109 To change a value for each item, enter a desired numeric value and press the corresponding field. To select a desired print unit data, either press either [<] or [>] button, or enter the numeric data and press the “UNIT No.” field. UNI-7 Service Manual...
  • Page 110 Chapter 7 SETUP MODE To display the List: Unit screen, just press the “UNIT No.” field without numeric entry. To change the pages, press either [ ] or [ ] button. UNI-7 Service Manual...
  • Page 111 To display the detail image, press the [DETAIL IMAGE] button. To move the format position to a desired direction, press the [ ] [ ] [ ] [ ] buttons. Press the [ESC] key on the key sheet exit from the current menu. UNI-7 Service Manual...

  • Page 112: Label Setting

    Select one of the following print speeds: 1: 80mm/sec 2: 100mm/sec PRINT DENSITY Select a desired print density level (0 – 9). FORMAT NO. Enter a numeric value and press this field. ITEM NO. Enter a numeric value and press this field. 7-10 UNI-7 Service Manual...

  • Page 113: Label Format Setting

    The Label Format List screen appears. Press to select a desired format field and press the [DETAIL] button. The Label Format (Basic) screen appears. Refer to steps 6 through 16 in section 7.2 for further procedures. UNI-7 Service Manual 7-11...
  • Page 114 EXAMPLE “LABEL FORMAT 2” Press to select a desired field for each print-related item on the screen. Press the [POSITION] tab and press to select a desired field for each control-related item Press the Return button. 7-12 UNI-7 Service Manual...

  • Page 115: Barcode Setting

    Enter a desired numeric value for each item and press the corresponding field. Press the [POS CODE] tab to display the Barcode (POS Code) screen. Then, select a desired POS code type by using the [>] and [<] buttons. UNI-7 Service Manual 7-13...
  • Page 116 Press the [POS FORMAT] tab to display the Barcode Format selection screen. The following Barcode Format list screen appears. Press to select a desired field to determine the barcode format. Press either [ ] or [ ] button to change the pages. 7-14 UNI-7 Service Manual...
  • Page 117 Select one of the following RSS expanded formats: RSS EXPANDED FORMAT 1: (01) (3922) (3202) 2: (01) (3922) (3202) (15) Press the [ITEM CODE] tab to display the Item Code screen. Press to select the code digits for each digit set. UNI-7 Service Manual 7-15...
  • Page 118 Chapter 7 SETUP MODE Press the Return button to return to the Menu Select screen. 7-16 UNI-7 Service Manual...

  • Page 119: Custom Barcode Setting

    CUSTOM BARCODE SETTING Press the “CUSTOM BARCODE” field on the screen. The Custom Barcode List screen appears. Press the [NEW] button on the screen. The following confirmation screen appears. Press the [ENTER] button on the screen for confirmation. UNI-7 Service Manual 7-17...
  • Page 120 Press the [EDIT] button on the screen. The following text edit screen appears. Enter a desired text according to the procedure described in Appendix “Text Editing”. EXAMPLE “CUST BARCODE 1” Press the [ESC] key on the key sheet. 7-18 UNI-7 Service Manual...
  • Page 121 The Custom barcode screen with edited title name appears. Then, press the selected (highlighted) field on the screen. The following ID list screens appear. Press either [ ] or [ ] button to change the pages. UNI-7 Service Manual 7-19...
  • Page 122 Then, the following screen appears. To continue further registration, press to select a desired field on the screen. EXAMPLE “2” Press to select a next desired item on the list. To end registration, press the Return key on the screen. 7-20 UNI-7 Service Manual...

  • Page 123: Menu Tiltle Editing

    Press the “MENU EDIT” field on the screen. The Menu Title (Operate) screen appears. Press either [ ] or [ ] button to change the pages Press to select a desired field on the screen, and press the [EDIT] button. UNI-7 Service Manual 7-21...
  • Page 124 Enter a desired text according to the procedure described in Appendix “Text Editing”. EXAMPLE “ACCUMULATION 1” Press the [ESC] key on the key sheet. The following confirmation screen appears. Press the [SAVE] button on the screen for confirmation. 7-22 UNI-7 Service Manual...
  • Page 125 Press the [TOTAL] tab on the screen. Press either [ ] or [ ] button to change the pages. Press the [PROGRAM] tab on the screen. Press either [ ] or [ ] button to change the pages. UNI-7 Service Manual 7-23...
  • Page 126 Chapter 7 SETUP MODE 7-24 UNI-7 Service Manual...
  • Page 127 Chapter 7 SETUP MODE Press the [SETUP] tab on the screen. Press either [ ] or [ ] button to change the pages. UNI-7 Service Manual 7-25...
  • Page 128 Chapter 7 SETUP MODE Press the [ADJUST] tab on the screen. Press either [ ] or [ ] button to change the pages. 7-26 UNI-7 Service Manual...

  • Page 129: Operation Setting

    The Operation Setting (Call) screen appears. Then, press to select a desired field for each item. Press the [PRODUCTION] tab on the screen. The Operation Setting (Product) screen appears. Then, press to select a desired field for each item. UNI-7 Service Manual 7-27...
  • Page 130 Chapter 7 SETUP MODE Press the [TIMER] tab on the screen. The Timer Setting screen appears. Then, enter a desired numeric value for each item and press the corresponding field. 7-28 UNI-7 Service Manual...

  • Page 131: Error Process Setting

    Press the “ERROR PROCESS” field on the screen. The Error Process (Issue) screen appears. Press to select a desired field for each item. Press the “CALL TIME” tab to display the Error Process (Call) screen. Then, press to select a desired field. UNI-7 Service Manual 7-29...
  • Page 132 Chapter 7 SETUP MODE Select the “COMMON” tab to display the Error Process (Common) screen. Then, press to select a desired field. 7-30 UNI-7 Service Manual...

  • Page 133: Error Log Display

    Chapter 7 SETUP MODE ERROR LOG DISPLAY Press the “ERROR LOG” field on the screen. The Error Log (Display) screen appears. Press the [ ] or [ ] button when changing the pages. UNI-7 Service Manual 7-31...

  • Page 134: Traceability Setting

    Chapter 7 SETUP MODE 7.10 TRACEABILITY SETTING Press the “TRACEABILTY SETUP” field on the screen. The Traceability screen appears. Then, press to select a desired field for each item. 7-32 UNI-7 Service Manual...

  • Page 135: Dual Currency Setting

    7.11 DUAL CURRENCY SETTING Press the “DUAL CURRENCY” field on the screen. The Dual Currency screen appears. Then, enter a desired numeric value for each input item, and press to select a desired field for each selection item UNI-7 Service Manual 7-33...

  • Page 136: Price Dounding Setting

    Chapter 7 SETUP MODE 7.12 PRICE DOUNDING SETTING Press the “PRICE ROUNDING” field on the screen. The Price Rounding screen appears. Then, press to select a desired field for each item 7-34 UNI-7 Service Manual...

  • Page 137: Country Setting

    Chapter 7 SETUP MODE 7.12 COUNTRY SETTING Press the “COUNTRY” field on the screen. The Country screen appears. Then, press to select a desired country and language. UNI-7 Service Manual 7-35...

  • Page 138: File Save / Load

    The External File Input screen appears for loading the USB memory data to the main memory. To display the File InOut (Detail) screen, press the [DETAIL] button. Press to select a desired field for each item. 7-36 UNI-7 Service Manual...
  • Page 139 Press to select a desired field for each item. Press the “EXT. DATA DEL” tab to display the external data delete screen Be sure to press to select a desired data type in the “DATA” field. UNI-7 Service Manual 7-37...
  • Page 140 Chapter 7 SETUP MODE Press the “INTERNAL INIT” tab to display the data initialization screen. Press the [ ] or [ ] button when changing the pages. 7-38 UNI-7 Service Manual...
  • Page 141 Chapter 7 SETUP MODE UNI-7 Service Manual 7-39...
  • Page 142 Chapter 7 SETUP MODE Press to select desired files for initialization, and press the [EXECUTE] button. The following confirmation screen appears. Then, press the [EXEC] button to execute file initialization. 7-40 UNI-7 Service Manual...

  • Page 143: Chapter 8 Adjustment Mode

    The Adjustment Menu screen appears. Enter “495344” and press the [PLU] key on the key sheet to enter Service Mode. Hidden menus come up on the screen. Press the [ ] or [ ] button when changing the pages. UNI-7 Service Manual...
  • Page 144 Chapter 8 ADJUSTMENT MODE UNI-7 Service Manual...

  • Page 145: Key Check

    Press the “KEY CHECK” field on the screen. The Key check screen appears. Press any keys on the membrane key sheet and confirm that the corresponding key colors on the screen change into green. Press the “VIBRATOR” tab to display the Key Vibrator screen. UNI-7 Service Manual...
  • Page 146 Chapter 8 ADJUSTMENT MODE Press to select whether or not to enable the vibration function. Then, press the [+] or [-] button to get a desired value. UNI-7 Service Manual...

  • Page 147: Program Number

    Chapter 8 ADJUSTMENT MODE PROGRAM NUMBER Press the “PROGRAM No.” field on the screen. The Program Number screen appears. Then, confirm the program numbers used in this machine. UNI-7 Service Manual...

  • Page 148: Memory Clear

    Chapter 8 ADJUSTMENT MODE MEMORY CLEAR Press the “MEMORY CLEAR” field on the screen. The Memory Clear screen appears. To clear the master data, press the [CLEAR] button. To initialize the system data, press the [INIT.] button. UNI-7 Service Manual...
  • Page 149 Chapter 8 ADJUSTMENT MODE To set the test data, press the [SET] button. The following confirmation screen appears. Then, press the [EXEC] button for execution. UNI-7 Service Manual...

  • Page 150: Printer Adjustment

    Then, select a desired printer by using either [<] or [>] button. Enter a desired numeric value for each item and press the corresponding field. Select a desired test print type and head type by using either [<] or [>] button. UNI-7 Service Manual...
  • Page 151 Perform back feed adjustment by entering a desired numeric value for each item and pressing the corresponding field Press a desired field to select whether or not to use the head temperature rise protect function. When initializing the printer, press the [PRINTER INITIAL] button. Press the [EXEC] button for execution. UNI-7 Service Manual...
  • Page 152 When initializing the thermal head, press the [HEAD INITIAL] button. Press the [EXEC] button for execution. Press the [HEAD CHECK] button to check whether the thermal head functions properly or not. You can hear the beep sound when the head is functioning properly. 8-10 UNI-7 Service Manual...
  • Page 153 Select a desired print density level by using either [-] or [+] button, or, pressing the corresponding field after numeric data entry. When initializing the printer, press the [PRINTER INITIAL] button. Press the [EXEC] button for execution. UNI-7 Service Manual 8-11...
  • Page 154 Select a desired label type by using either [<] or [>] button. 0: Receipt 1: 130LA-1 3: 150LA-1 Select a desired print density level by using either [<] or [>] button, or, pressing the corresponding field after numeric data entry. 8-12 UNI-7 Service Manual...
  • Page 155 Press to select a desired field for each item. Enter a desired numeric value for each item and press the corresponding field. When initializing the printer, press the [PRINTER INITIAL] button. Press the [EXEC] button for execution. UNI-7 Service Manual 8-13...
  • Page 156 0: None 1: Label <Print Speed> 1: 80mm/sec 2: 100mm/sec Select a desired numeric value for sensor scope and sensitivity levels by using either [-] or [+] button, or, pressing the corresponding field after numeric data entry. 8-14 UNI-7 Service Manual...
  • Page 157 Enter a desired numeric value for each item and press the corresponding field. Press a desired field to select whether or not to use the back feed function. To display the detailed data of the printer, press the [DETAIL] button. UNI-7 Service Manual 8-15...

  • Page 158: Calibration

    Press to select either the “WEIGHT” or “VOLTAGE” field. AREA SET Enter a desired numeric value and press this field. Place the weights of the same weight as the upper limit of the weighing capacity on the weigh platter. 8-16 UNI-7 Service Manual...
  • Page 159 If the A/D and SPAN A/D values are not “95000” and ”75000” respectively, remove the weights from the platter. Then, place them on the platter again and press the [SPAN] button to check that the A/D display field shows “95000”, and the SPAN A/D display field shows ”75000”. UNI-7 Service Manual 8-17...
  • Page 160 To memorize the adjusted span value, press the Memory button located on the main board inside of the machine with a nonconductive and thin material such a wooden stick through the hole on the upper case. 8-18 UNI-7 Service Manual...

  • Page 161: Downloading

    Press the “DOWNLOAD” field on the screen to display the Download (Main) screen. When loading data from the main memory to the USB memory, press to select the 2-1. [MAIN USB] button and press the [EXECUTE] button UNI-7 Service Manual 8-19...
  • Page 162 2-3. The progress screen appears. The beep sounds when completed. When loading data from the USB memory to the main memory, press to select one of the 3-1. [USB MAIN] buttons and press the [EXECUTE] button 8-20 UNI-7 Service Manual...
  • Page 163 Chapter 8 ADJUSTMENT MODE 3-2. The Down Load (Main) screen appears. Press to select desired folders. 3-3. The following confirmation screen appears. Then, press the [EXEC] button for execution. 3-4. The progress screen appears. UNI-7 Service Manual 8-21...
  • Page 164 Chapter 8 ADJUSTMENT MODE 3-5. The following message screen appears. Then, pull out the USB from the port, and turn the power OFF and ON. 8-22 UNI-7 Service Manual...

  • Page 165: Option Check

    Press the “OPTION CHECK” field on the Menu Select screen. The Option Check (USB) screen appears. Press the [EXECUTE] button to perform a memory test. The “OK” message appears when the memory test has been completed. UNI-7 Service Manual 8-23...
  • Page 166 Chapter 8 ADJUSTMENT MODE Press the “DRAWER” tab to display the Option Check (Drawer) screen. Then, press the [EXECUTE] button for each drawer port. The “EXECUTION” message appears. The beep sounds when the execution has been completed. 8-24 UNI-7 Service Manual...

  • Page 167: Display Capture

    Chapter 8 ADJUSTMENT MODE DISPLAY CAPTURE Press the “DISPLAY CAPTURE” field on the screen. Press to select a desired field to decide whether or not to capture screen data. UNI-7 Service Manual 8-25...

  • Page 168: Model Setting

    Chapter 8 ADJUSTMENT MODE 8.10 MODEL SETTING Press the “MODEL” field on the screen. The Model Setting screen appears. Press to select a desired model. 8-26 UNI-7 Service Manual...

  • Page 169: Chapter 9 Error Screens

    PRESERVATION WAY No. [*] IS NOT STORAGE CONDISTION MASTER IS PROGRAMMED NOT PROGRAMMED DELETE IT? TEMPERATURE MASTER IS NOT TEMPERATURE No. [*] IS NOT PROGRAMMED PROGRAMMED DELETE IT? FREE1 No. [*] ISN'T PROGRAMMED. FREE1 MASTER ISN'T REGISTERED DELETE IT? UNI-7 Service Manual...
  • Page 170 ABNORMAL RESULT AS ABNORMAL. IT CANCELED TOTAL DIGNOSYS PROCESS 274- ABNORMAL WITH FOLLOWING REASON. - IT FAILED IN DIGYNOSYS START PROCESS IT CANCELED TOTAL DIGNOSYS PROCESS 274- ABNORMAL WITH FOLLOWING REASON. - IT FAILED IN GETTING IT. UNI-7 Service Manual...
  • Page 171 RE-PROGRAM TARE WEIGHT. TARE LIMIT OVER (MAX 9.99lb) IF YOU RELEASE ERROR TARE WEIGHT IS 0lb SET TARE WEIGHT FREE 6 FREE 7 FREE 8 FREE 9 FREE 10 FREE 11 FREE 12 FREE 13 FREE 14 FREE 15 UNI-7 Service Manual...
  • Page 172 YOU CAN NOT DO THE WORK. LABEL IS REMAINING REMOVE LABEL THERE IS NO CF CARD CHECK CF CARD. THERE IS NO DICTIONARY FILE CHECK CF CARD. POWER IS ON CHECK SCALE FOR STARTING PRODUCTION. NO USB MOMORY CHECK USB MEMORY UNI-7 Service Manual...
  • Page 173 DOES NOT MAKE (STOP) CHECK. THERMAL HEAD IS WORN OUT WITHIN FORMAT. 715- THERMAL HEAD IS WORN OUT FOR NEED TO CHANGE THERMAL HEAD. PRINTER 1 DO YOU WANT TO MAKE FURTHER CHECK? (EXEC) TO CHECK. (STOP) NOT TO CHECK UNI-7 Service Manual...
  • Page 174 CAN NOT PRINT LABEL. CAN NOT DO LABELLING. ERROR ID NOS. 1601 – 1624 ID NO. TITLE TEXT SPAN ADJUSTMENT FOR SCALE IS 1601 RE-SET SPAN NOT COMPLETED SET DATA ONEDIGIT DIFFERENT ERROR. 1624 DATA SET ERROR ONE DIGIT CHECK. UNI-7 Service Manual...
  • Page 175 CHECK THE CONTENTS FOR THE MASTER. IT IS NOT PROGRAMMED IN CALORY CALORY No. [*] IS NOT PROGRAMMED. 9653 MASTER CHECK THE CONTENTS FOR MASTER. DATA CAN NOT BE RENEWED. 9690 MEMORY IS FULL IT DELETES UNNECESSARY MASTER IN THE MASTER MACHINE. UNI-7 Service Manual...
  • Page 176 Chapter 9 ERROR SCREENS UNI-7 Service Manual...

  • Page 177: Appendix Text Editing

    Used to specify a normal left. Also used to select character style. characters for changing the style. Used to select either lower-case or upper-case Used to specify a bold character mode for a text to be character style. entered. Uni-7 User’s Manual...
  • Page 178 Used to specify a revered Used to begin a new character character. line. Used to select either a Used to enter a space at the lower-case or upper-case place where the cursor is mode for a character to be positioned. entered. Uni-7 User’s Manual...

  • Page 179: Normal Character Registration

    Select a desired character size by using the [Size] key on the key sheet. The selected size is displayed in the “FONT” display field. Press the [Lower Case] key on the key sheet to select whether to use upper-case characters or lower-case characters. Uni-7 User’s Manual...
  • Page 180 Appendix TEXT EDITING Enter desired characters using alpha-numeric keys on the key sheet or the screen. Upper-case characters Lower-case characters Uni-7 User’s Manual...
  • Page 181 To change to a new line, press the [New Line] key on the key sheet. Enter desired characters. To finalize the editing, press the [ESC] key on the key sheet. The confirmation screen appears. Then, press the [SAVE] button to save the data. Uni-7 User’s Manual...

  • Page 182: Special Character Registration

    To select a desired character style using the following keys. The selected style is displayed in the “STYLE” display field. EXAMPLE Select reversed characters. Enter desired characters using alpha-numeric keys on the key sheet or the screen. Uni-7 User’s Manual...
  • Page 183 Appendix TEXT EDITING Press the [ESC] key on the key sheet. The confirmation screen appears. Then, press the [SAVE] button to save the data. Uni-7 User’s Manual...

  • Page 184: Line Deletion

    Confirm that the text edit screen for a desired PLU is displayed. To delete the character line, press the [Line Delete] key on the key sheet. Press the [ESC] key on the key sheet. The confirmation screen appears. Then, press the [SAVE] button to save the data. Uni-7 User’s Manual...

  • Page 185: Character Deletion

    To Make a correction for a misspelled word, move the cursor to a place where misspelling is made by using the [→] or [←] key. “GAUDA” → “GOUDA” EXAMPLE Press the [Character Delete] key on the key sheet to delete the misspelled character. Uni-7 User’s Manual...
  • Page 186 Appendix TEXT EDITING Enter the correct character using the alpha-numeric keys. Press the [ESC] key on the key sheet. The confirmation screen appears. Then, press the [SAVE] button to save the data. A-10 Uni-7 User’s Manual...

  • Page 187: Character Backspacing

    CHARACTER BACKSPACING To delete a wrong character that was just entered, press the [Back Space] key on the key sheet to move the cursor back by one character. “E” → “A” EXAMPLE Enter a correct character. Uni-7 User’s Manual A-11...
  • Page 188 Appendix TEXT EDITING Complete the text. Press the [ESC] key on the key sheet. The confirmation screen appears. Then, press the [SAVE] button to save the data. A-12 Uni-7 User’s Manual...
  • Page 189 Design and specifications are subject to change without notice. 44 SANNO-CHO, SHOGOIN, SAKYO-KU KYOTO, 606-8392 JAPAN PHONE: 81-75-771-4141 FACSIMILE: 81-75-751-1634 URL: http://www.ishidajapan.com...
