TT-3000E mini-C GMDSS System
9.4 TT-3616C S
Model
General Specifications
Dimensions (H x W x D)
Weight
Mountings
Power requirements
Connector
Fuse
Temperature
Relative humidity
Vibration operational
Vibration survival
Shock

Table 19 TT-3616C Technical Specifications

PECIFICATIONS
TT-3616C GMDSS Interconnection Box
The unit is in full compliance with the
Inmarsat CN114, IEC 60945 and Wheel
Mark specifications.
46 mm x 256 mm x 220 mm
1.6 Kg
Wall mounting, 4 holes Ø6 mm
Floating DC.
Nominal voltage range is 12V to 24V.
Working voltage range is 10.5V to 32V.
Max current 0.5A (including power
distributed to alarm panels, excluding
power distributed to TT-3026C).
2 x DSUB9 Female.
67 x Spring type terminals (max. 2.5mm
5 A ATO® type (spare fuse included)
-25°C to 55°C operating,
-40°C to 80°C storage
95% non-condensing at 40°C
Random vibrations:
Sinusoidal vibrations: 2-15.8 Hz: 2.54 mm
Random vibrations:
Sinusoidal vibrations: 2-15.8 Hz:2.54 mm
Half sine: 20g/11ms
93/97
Installation Manual
5-20 Hz:0.005 g²/Hz
20-150 Hz:-3 dB/oct
(0.5 g rms.)
peak ampl.
10-100 Hz: 1.0 g
peak acceleration
5-20 Hz:0.05g²/Hz
20-150 Hz:-3 dB/oct
(1.7g rms.)
peak ampl.
10-100 Hz: 1.0g
peak acceleration
