Tt-3026C Specifications - Thrane&Thrane SAILOR TT-3000E mini-C GMDSS System Installation Manual

TT-3000E mini-C GMDSS System
9.1 TT-3026C S
Model
General Specifications
Transmit Frequency
Receive Frequency
Channel Spacing
Modulation
Ambiguity Resolution
Coding
Data Rate
RX Frame Length
TX Signalling Access Mode
TX Message Channel
Terminal Interface
I/O Interface:
System Set-up
DC Power Source
Fuse
Ambient Temperature
Dimensions
Weight
Note 1: Inmarsat frequencies:
PECIFICATIONS
TT-3026C
Meets all INMARSAT specifications for the
Inmarsat mini-C Network for Land mobile and
Maritime terminals.
R&TTE
1626.5 to 1660.5 MHz.
1525.0 to 1559.0 MHz.
5 / 2.5 / 1.25 kHz.
1200 symbols/sec BPSK.
Unique word.
R ½ K=7 convolutional code, (interleaved code
symbols RX).
600 bit/sec.
8.64 seconds.
Slotted ALOHA.
TDMA & FDMA, interleaved code symbols.
EIA/TIA-232-E DTE interface. CCITT
Rec.V.24/28, 4800-115200 Baud IA-5 code
Six dedicated In/Out pins.
Open-collector. Sinks 25 mA each.
S-RAM Battery backup
Floating DC
Nominal voltage range is 12V to 24V
Working voltage range is 10.5V to 32V
Max limit 100VA
Max current 4A
Max power 32W
Power: RX: 1.8W ,TX: 23 W @ 12V supply
Self recovering Poly fuse
-35°C to 55°C operating
-40°C to 80°C storage.
Ø=163 mm H: 143 mm
1.10 kg
TX: 1626.5 – 1646.5 MHz
RX: 1530 – 1545 MHz
89/97
Installation Manual
note 1
note 1
