Table 4 TT-3000E mini-C GMDSS System Fuses

The fuse located in the TT-3616C GMDSS Interconnection Box
serves as fuse for the TT-3616C internal supply as well as fuse
for the power delivered to the TT-3026C mini-C Transceiver,
hence the high value of 5A.
Location
Internal self reset able
poly fuse
Internal self reset able
poly fuse
No fuse
Internal self reset able
poly fuse
Internal self reset able
poly fuse
Internal self reset able
poly fuse
Internally accessed,
remove top cover
Internally accessed,
remove top cover
Externally accessed.
Internally accessed,
remove top cover
31/97
Installation Manual
Fuse size
NA
NA
NA
NA
NA
NA
®
5 A ATO type
(As used in cars)
1.5A mT.
1 A mT (230VAC)
2 A mT (110VAC)
®
10 A ATO type
(As used in cars)
