TT-3000E mini-C GMDSS System
4.7.1.1
B
RACKET
The outline and dimensions for a bracket mounted AP5042 are
shown in Figure 42.
All dimensions are in millimetres
Figure 42 Outline & dimensions - bracket mount
M
OUNT
100
128
min. 150
Space for cable entry
66/97
Installation Manual
31.5
60.5
