TT-3000E mini-C GMDSS System
Operating system
Inmarsat-C
Protocol support
TT-3026C
mini-C
Transceiver
Maximum
transmission
length
Solar Radiation
Precipitation
Ice
Velocity
Vibration
Operational
Vibration Survival
Shock

Table 16 TT-3026C Technical Spectifications

The TT-3026C mini-C transceiver makes use of eCos™
operating system.
Message transmission and reception with IA-5, ITA-2 and
binary transfer to/from the following destinations:
Telex
PSTN (telephone modems and fax modems)
PSDN (X.25 network)
EGC message reception with automatic geographical area
selection.
Polling and data reporting with automatic transmission of
position reports down to a recommended minimum of 1 per 5
minutes.
Special Access Codes
DNID Messaging
Program Unreserved Data reporting
Transmit message size: Max 10Kbyte
Receive storage: > 32 Kbytes.
Inmarsat-C/GPS omnidirectional antenna, RHC polarised.
G/T: -23.7 dB/K at 5° elevation
EIRP: 7 dBW dB at 5° elevation.
Temperature: -35°C to 55°C operating,
-40°C to 80°C storage.
10 Kbytes.
Max. flux density 1200W/m2.
Up to 100 mm/hour, droplet size 0.5 to 4.5 mm
Up to 25 mm.
Max velocity up to 140 km/hour (87mph).
Random 5-20 Hz: 0.005 g 2 /Hz
20-150 Hz: -3dB/oct. (0.5g RMS).
Random 5-20 Hz: 0.05 g 2 /Hz
20-150 Hz: -3dB/oct. (1.7g RMS).
Half sine 20g/11ms
90/97
