TT-3000E mini-C GMDSS System
4.7.1.2
F
LUSH MOUNT
The outline and dimensions for a flush mounted AP5042 are
shown in Figure 44.
All dimensions are
in millimetres
Figure 44 Outline and dimensions - flush mount
The drilling template is shown in Figure 45 and the 3
dimensional assembly drawing is shown in Figure 46.
140
min. 150
Space for cable entry
68/97
Installation Manual
Panel
Mounting
Bracket
9.6
