- Page 1 USER MANUAL SAILOR 100 Satellite TV...
- Page 3 SAILOR 100 Satellite TV User Manual Document number: 98-136311-A Release date: September 21, 2012...
- Page 4 Disclaimer Any responsibility or liability for loss or damage in connection with the use of this product and the accompanying documentation is disclaimed by Thrane & Thrane. The information in this manual is provided for information purposes only, is subject to change without notice and may contain errors or inaccuracies.
- Page 5 Safety summary The following general safety precautions must be observed during all phases of operation, service and repair of this equipment. Failure to comply with these precautions or with specific warnings elsewhere in this manual violates safety standards of design, manufacture and intended use of the equipment.
- Page 6 About the manual Intended readers This manual is a user manual for the SAILOR 100 Satellite TV system. This manual is intended for anyone who is using or intends to use this system. No specific skills are required to operate the SAILOR 100 Satellite TV. However, it is important that you operate the system according to the guidelines in this manual.
- Page 7 Related documents The below list shows the documents related to this manual and to the SAILOR 100 Satellite TV system. Document Title and description number SAILOR 100 Satellite TV Installation manual 98-136280 Control Panel Installation manual (TT-6006A 98-130088 and TT-6007A Message Terminal)
-
Page 9: Table Of Contents
Table of contents Chapter 1 Introduction SAILOR 100 Satellite TV ............1 User interfaces ..............2 ......2 Control Panel for handling satellite profiles ......2 ACU display for status and system parameters Chapter 2 Operation Control Panel ..............3 ..............3 Getting started ...........5 Creating or editing a profile .............8... - Page 10 Table of contents App. A Conformity SAILOR 100 Satellite TV .............23 ..............23 CE (LVD & EMC) Index ..................25 viii...
-
Page 11: Sailor 100 Satellite Tv
Chapter 1 Introduction SAILOR 100 Satellite TV The SAILOR 100 Satellite TV is a maritime satellite TV antenna for high-quality worldwide TV reception. It consists of the following units: • Above Deck Unit (ADU) • Antenna Control Unit (ACU) •... -
Page 12: User Interfaces
User interfaces Control Panel for handling satellite profiles The user interface of the SAILOR 100 Satellite TV is the Control Panel. It has a touch screen. You can tap through settings and menus to handle satellite profiles, show status information and system messages. The following screen shows the Dashboard. -
Page 13: Operation
Chapter 2 Operation The SAILOR 100 Satellite TV has the following user interfaces: • Control Panel • Keypad and menus of the ACU There is also a web interface for installation and advanced setup. For further details see the SAILOR 100 Satellite TV Installation manual. - Page 14 If connected directly to the ACU, make sure that the DHCP server Note has been enabled on that port. For details on ACU network configuration see the SAILOR 100 Satellite TV Installation manual. 2. Press the on/off button. A couple of start-up screens are displayed.
-
Page 15: Creating Or Editing A Profile
Chapter 2: Operation 3. The Dim button is used to dim the light in the Control Panel. Push and hold to dim the display more/less. Each new push changes direction between more and less. Now you can create satellite profiles. Creating or editing a profile To create or edit a profile, i.e. - Page 16 Chapter 2: Operation 5. Tap the field Satellite. A new window is displayed. Tap and scroll to find the wanted satellite, then tap on a satellite to select it. The list is sorted as follows: 180°W -> 0° -> 180°E. Profile handling Default satellite in the list Create new profile The satellite closest to the ship’s...
- Page 17 Chapter 2: Operation DVB-S / DVB-S2: By selecting DVB-S / DVB-S2, it is possible to configure the system to track a specific transponder. • Polarisation: Linear Horizontal, Linear Vertical, Circular Left hand or Circular Right hand. • Tracking frequency: Frequency of the transponder (e.g. 11.362 GHz). •...
-
Page 18: Selecting The Active Profile
Chapter 2: Operation Selecting the active profile To change the active profile, select another profile from the list of created profiles. When you select another profile, the antenna moves to the Note new position and goes through the acquisition procedure. This may take a couple of minutes. -
Page 19: Deleting A Profile
Chapter 2: Operation Deleting a profile You can delete profiles that you don’t use anymore. You cannot delete the currently active profile. To delete a profile, do as follows: 1. Tap the menu icon 2. Select Settings. 3. Select Delete profile. 4. -
Page 20: Event List
Chapter 2: Operation Event list This list provides active events and history of the system. Notifications are earlier events, they are cleared after 24 hours. There are two ways to display the Event list: Tap the menu icon and tap Event list. 1. -
Page 21: Help
Tap the menu icon and tap About. About provides the following information: • Software version of the SAILOR 100 Satellite TV application. Software version of the ACU is shown on the Dashboard page in the section Unit information. • IP address of the Control Panel •... -
Page 22: Keypad And Menus Of The Acu
(warnings, errors and information) and how the system has been configured. Use the keypad to navigate through the menu tree. Signal strength 1. Current status of the SAILOR 100 Satellite TV: NOT READY (Waiting for input from GNSS, e.g. GPS) READY (no satellite profile selected) -
Page 23: Navigating The Menus
Chapter 2: Operation 2. Current menu. See The menu tree on page 14. GPS signal is received from the GPS module, 3. GPS: OK or —. Ship heading data received from the ship’s gyro 4. HDG: , OK or —. 5. -
Page 24: The Menu Tree
Chapter 2: Operation The menu tree In the menu tree you can see how the system has been configured. You can also enter satellite information directly, if it is necessary to change the satellite information and you cannot use a connected PC and the web interface. ANT-1 ANTENNA STATE POINTING... - Page 25 Description menu MAIN View with current status of the SAILOR 100 Satellite TV. This view is displayed after a time out of 10 minutes. Press any key (except left arrow) to enter the menu at MAIN. New events are shown in this display. If an event is displayed, press OK to jump directly to the menu EVENTS for viewing the currently active events.
- Page 26 MASK 1/2 Current netmask for LAN 1 and LAN 2. PORT 3 IP (LAN 3) Current IP address of the SAILOR 100 Satellite TV web interface (default: 192.168.0.1). MASK 3 (LAN 3) Current netmask of the SAILOR 100 Satellite TV web interface (default: 255.255.255.0).
- Page 27 Chapter 2: Operation SATELLITE menu Description POSITION Position of the current satellite. RX POLARISATION Linear polarisation: HORIZONTAL, VERTICAL Circular polarisation: LEFT HAND, RIGHT HAND. RX FREQUENCY Ku band receiving frequency of the active satellite. EVENT Description menu <EVENT> In this menu all active events are listed. Use to go through the active events.
-
Page 28: Adjusting Brightness Of The Display
Chapter 2: Operation Adjusting brightness of the display To adjust the brightness do the following: 1. Press and hold OK for a short moment until BRIGHTNESS XXX% is displayed (XXX is the current brightness value). 2. Hold OK pressed + press for lighter or for darker display. -
Page 29: Troubleshooting
Chapter 3 Troubleshooting This chapter gives guidelines for troubleshooting and provides an overview of the different means of status signalling. It has the following sections: • LEDs on the ACU • Troubleshooting guide • Error messages • Service and repair... -
Page 30: Leds On The Acu
Chapter 3: Troubleshooting LEDs on the ACU The ACU has 3 LEDs: Power, TV Ready and Fail/Pass LED. Behavior Description Power Steady green Power supply OK Steady red Power supply failure No power TV Ready Steady green Tracking satellite. Not tracking satellite. Fail/Pass Steady red A fault which prevents operation is present in... -
Page 31: Troubleshooting Guide
Chapter 3: Troubleshooting Troubleshooting guide Error messages Active errors are indicated by a yellow triangle on the Dashboard page of the Control Panel. To see further info see Event list on page 10. Service and repair Should your Thrane & Thrane product fail, please contact your dealer or installer, or the nearest Thrane &... - Page 32 Chapter 3: Troubleshooting If the original shipping carton is not available, the following general instructions should be used for repacking with commercially available material. 1. Wrap the defective unit in heavy paper or plastic. Attach a tag indicating the type of service required, return address, part number and full serial number.
-
Page 33: Sailor 100 Satellite Tv
Conformity SAILOR 100 Satellite TV CE (LVD & EMC) The Thrane SAILOR 100 Satellite TV is CE certified (LVD &EMC directives) as stated in the “Declaration of Conformity with LVD and EMC Directives”, enclosed in copy on the next page. - Page 35 Index Index edit satellite profile, 5 display menus and keypad, 12 error messages, 21 ACU LEDs, 20 event list, 21 view, 10 events display in Control Panel, 10 back function, 4 brightness in display, 18 IP address Control panel, 11 CE compliance, 23 conformity, 23 Control Panel...
- Page 36 Index service, 21 shipment, 21 navigate software version Control Panel, 4 ACU, 11 display menus, 13 control panel, 11 start-up, 4 system ACU reset, 18 system reset, 18 order number manual, i tracking properties, 6 packing for shipment, 21 polarisation, 6 DVB-S, 7 power on, 4 warranty, 21...
- Page 38 98-136311-A info@thrane.com thrane.com •...
