Attach the Monitors

Warning! ARMDUOSS is designed to display two Monitors between 15 and 24
inches in size. The maximum weight capacity of ARMDUOSS is a total of 35.2 lb.
(16 kg), with each Monitor Mount able to hold 17.6 lb. (8 kg).
Note: To prevent scratching during the installation process, you should handle
the surface of the Monitors with care.
Figure 4
Pole
1. To loosen the Plates on the Crossbar , turn the Thumbscrews at the bottom of
the Plates counterclockwise.
Figure 5
2. Move the Plates right or left until they're in the desired position (Figure 5).
3.
To secure the Plates in place on the Crossbar, turn the Thumbscrews at the
bottom of the Plates clockwise.
4.
To move the VESA Monitor Mounts up or down, turn the Height-Adjustment
Screws at the top of the Plates counterclockwise or clockwise (Figure 6).
Move left
or right
8
Plate
Thumbscrew
Move left
Shown with VESA Mounts
or right
already installed
