Figure 7
VESA
Monitor
Mount
Adjusting the
Tilt Adjustment
The Monitors can be tilted to accommodate different viewing angles (15 degrees
downward or upward).
•
Place both of your hands on either side of the Monitor and apply light pressure
either downward or upward. The Monitor will tilt to a maximum of 15 degrees in
either direction (Figure 9).
Figure 9
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
M4x12
mm
Screws
Monitors
10
Figure 8
VESA
Monitor
Mount
M4x30
mm
Screws
Plastic
Spacers
