Assembly

Warning! Make sure that all of the hardware is assembled se-
curely and checked for stability before you load the monitors.

Assemble the Base

Insert the M6x15 mm Screws through the three holes in the
1.
Baseplate and into the Pole (Figure 1).
Use the M4 Hex Key and turn the M6x15 mm Screws
2.
clockwise to tighten.
Figure 1
Baseplate
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Pole
M6x15 mm Screw
M4 Hex Key
