3.3

Setting with the Engineering Tool

Settings to the TN8 module can be done with the engineering tool.
For the operation method of the engineering tool, refer to "Unified
Controller nv series/Integrated Controller V series nV-Tool (Basic)
operation manual "(6F8C1290).
Connect the engineering tool and nv series controller via Ethernet.
The Ethernet connection in the nv controller can be made using the
built-in Ethernet of the CPU module or using the TN8 module. The figure
below illustrates how to engineer the configuration using the built-in
Ethernet of the CPU module (Figure 3-2 System configuration of the
setting example).
Set the IP address shown in Figure 3-2 to the CPU module. Using the
rotary switch of the CPU module, set the lowermost digit of the IP address
in hexadecimal (in this case, convert "28" into hexadecimal and set
"1C(h)," i.e. H=1，L=C ).
Set the dip switches DSW-5 and DSW-6 of the CPU module to OFF and
OFF, respectively.
For more information on the dip switches of the CPU module, refer to
"Unified Controller nv series Type 1 Function Manual" (6F8C1221) or
"Unified Controller nv series Type 2 Function Manual" (6F8C1362).
Note
• The switch setting becomes effective from the next startup. Restart the controller after
setting.
IP Address: 172.16.64.1
Engineering
Tool(PC)
Subnet mask: 255.255.192.0
IP Address: 172.16.64.28
Subnet mask: 255.255.192.0
Figure 3-2 System configuration of the example
Unified Controller nv series TC-net 100 (TN8) Module Operation Manual
3.4 Network Information
Ethernet
P
T
N
N
8
8
21
