3.6
Setting the RAS Information Block in Scan Transmission
The RAS information generated by the TN8 module can be expanded in
scan transmission. To register the RAS information generated by the TN8
module in scan blocks for transmission, use the following registration
conditions. For the registration method, refer to "3.3.2 Setting the scan
sending blocks."
RAS information block setting conditions
• BlockNo: 2048 - Station address (the value of the station address
• CntSlotNo: Slot number (0 to 7) where the TN8 module is installed
• Speed: Medium (M)
If the conditions above are met, the TN8 module generates RAS
information for the scan block for transmission.
The transmission of the RAS information block starts when a scan sending
start request is received from the host controller. After that, the
transmission of the RAS information block continues even if an error
occurs in the host controller.
The scan talker block must be set in the host controller making the scan
sending start request.
Important
• Do not write to this block from the application.
Table 3-5 shows the information configuration of the RAS information
block.
3.6 Setting the RAS Information Block in Scan Transmission
setting switch)
(Example: Block 2043 if the station address is 5)
Unified Controller nv series TC-net 100 (TN8) Module Operation Manual
47
