Chapter 3 Setting
3.2

Network Parameter Setting

The network parameters can be set with the operation mode setting
switches and station address setting switches.
For methods to set these switches, refer to "Table 3-1 Station address
setting" and "Table 3-2 Operation mode setting table."
For the TN8 module, the following network parameters must be set.
• IP address type
• Station address
Two IP address types are provided; nv series 1 and nv series 2. Also, it can
be set with the engineering tool.

3.2.1 Network ID and subnet mask

nv series 1 setting (Standard setting)
Use the operation mode setting switches to set the IP address type to "nv
series 1."
This is the standard setting of the unified controller system.
Network ID: 172.16.64.XX
(XX indicates the value of the station address setting switches)
Subnet mask : 255.255.192.0
nv series 2 setting
Use the operation mode setting switches to set the IP address type to "nv
series 2."
This setting is used for expansion of the TC-net 100, and not used
normally.
Network ID: 172.31.64.XX
(XX indicates the value of the station address setting switches)
Subnet mask : 255.255.192.0
Arbitrary setting
Use the operation mode setting switches to set the IP address type to
[Tool setting], and set IPF to [ON].
18
6F8C1360
