3.4 Network Information
3.4.5 LAN control information
In the system view, select the TN8 module, and select [LAN management
information (N)] from [Tool (T)] on the menu bar.
Figure 3-27
LAN management information selection screen
Displayed is the information on each node connected to TC-net 100LAN .
Figure 3-28 LAN management information screen
Unified Controller nv series TC-net 100 (TN8) Module Operation Manual
41
