Mounting and wiring - continued

Wiring

Decide during planning which function is to be connected and
where this will be.
1. Connect inputs and outputs
Here are the tables for the example:
Signal Module
S1
S2
S3
S4
P1
P2
1
Relay for valve
Relay for pump A.
(Difference pressostat)
Relay for pump B
(Two sensor thermostat)
AK-LM 340
Point Signal type /
Terminal
Active at
1 (AI 1) 1 - 2
Pt 1000
2 (AI 2) 3 - 4
Pt 1000
3 (AI 3) 5 - 6
Pt 1000
4 (AI 4) 7 - 8
Pt 1000
5 (AI 5) 9 - 10
6 (AI 6) 11 - 12
7 (AI 7) 13 - 14
AKS 32R-12
8 (AI 8) 19 - 20
9 (AI 9) 21 - 22
10 (AI 10) 23 - 24
11 (AI 11) 25 - 26
AKS 32R-12
12 (DO 1) 31 - 32
13 (DO 2) 33 - 34
14 (DO 3) 35 - 36
15 (DO 4) 37 - 38
16 (DO 5) 39-40-41
ON
17 (DO6) 42-43-44
18 (DO7) 45-46-47
ON
19 (DO8) 48-49-50
ON
24 -
25 -
RS8GV202 © Danfoss 2016-06
The function of the switch functions can be seen in the last column.
