Danfoss ADAP-KOOL AK-LM 340 User Manual page 19

Punkt
At the top the
signal input is
the left of the
two terminals.
At the bottom
the signal input
is the right of the
two terminals.
S
Pt 1000 ohm/0°C
P
AKS 32R
3: Brun
2: Blå
1: Sort
AKS 32
3: Brun
2: Sort
1: Rød
U
On/Off
AO
AK-LM 340
Signal Signal
type
Pt 1000
S...
AKS 32R /
AKS 2050
MBS 8250
-1 - xx bar
P...
AKS 32
-1 - zz bar
0 - 5 V
V...
0 - 10 V
Active at:
Day/
Night Closed
/
Door Open
Level
switch
0-10 V
RS8GV202 © Danfoss 2016-06
Point 1 2 3 4
Type AI1 AI2 AI3 AI4
Point 5 6 7
Type AO1 AO2 AO3
Signal Module
Terminal 9:
Terminal 10:
Terminal
11, 12:
(Cable screen)
Galvanic isolation:
AI 1-4 ≠ AO 1-2 ≠ AO 3-4
8
AO4
Point Terminal Signal type /Active at
1 (AI 1) 1 - 2
2 (AI 2) 3 - 4
3 (AI 3) 5 - 6
4 (AI 4) 7 - 8
5 (AO 1) 17 - 18
6 (AO 2) 19 - 20
7 (AO 3) 21 - 22
8 (AO 4) 23 - 24
12 V
5 V
19
