Point
At the top the
signal input is
the left of the
two terminals.
At the bottom
the signal input
is the right of the
two terminals.
S
Pt 1000 ohm/0°C
P
AKS 32R
3: Brown
AKS 2050
2: Blue
1: Black
AKS 32
3: Brown
2: Black
1: Red
U
On/Off
AK-LM 340
Signal Signal
type
Pt 1000
S...
AKS 32R
AKs 2050
MBS 8250
-1 - xx bar
P...
AKS 32
-1 - zz bar
0 - 5 V
V...
0 - 10 V
Active at:
Day/
Night
Closed
/
Door
Open
Defrost
RS8GV202 © Danfoss 2016-06
Point 1 2 3 4
Type AI1 AI2 AI3 AI4
Point 5 6 7
Type AI5 AI6 AI7
Signal Module
9:
Terminal
10:
Terminal
15:
Terminal
16:
Terminal
Terminal
11, 12, 13, 14:
(Cable screen)
8
AI8
Point
Terminal
1 (AI 1) 1 - 2
2 (AI 2) 3 - 4
3 (AI 3) 5 - 6
4 (AI 4) 7 - 8
5 (AI 5) 17 - 18
6 (AI 6) 19 - 20
7 (AI 7) 21 - 22
8 (AI 8) 23 - 24
12 V
5 V
5 V
12 V
Signal type /
Active at
