1. Controller
Type Function
AK-LM 340 Monitoring unit with PI regulation
2. Extension modules and survey of inputs and outputs
Type Analog
inputs
For sensors, pres-
sure transmitters
etc.
Controller 11
Extension modules
AK-XM 101A 8
AK-XM 102A
AK-XM 102B
AK-XM 103A 4
AK-XM 204A
AK-XM 204B
AK-XM 205A 8
AK-XM 205B 8
AK-XM 107A
AK-XM 208C 8
The following extension module can be placed on the PC board in the controller module.
There is only room for one module.
AK-OB 110
3. AK operation and accessories
Type Function
Operation
AK-ST 500 Software for operation of AK controllers
- Cable between PC and AK controller
Cable between zero modem cable and AK controller /
-
Cable between PDA cable and AK controller
- Cable between PC and AK controller
Accessories Power supply module 230 V / 115 V to 24 V d.c.
AK-PS 075 18 VA, 24 V d.c.
AK-PS 150 36 VA, 24 V d.c.
Accessories Real time clock for use in controllers that require a clock function, but are not wired with data communication.
AK-OB 101A Real time clock with battery backup.
Accessories Communication modules for controllers where modules cannot be connected continuously
AK-CM 102 Communication module
On the following pages there is data specific to each module.
AK-LM 340
On/Off outputs On/off supply voltage
(DI signal)
Relay Solid state Low voltage
(SPDT) (max. 80 V)
4 4
8
8
8
8
RS8GV202 © Danfoss 2016-06
Application
Monitoring of temperatures, pressure, voltage etc.
High volt- Pulse coun-
age ter
(max. 260 V) Low voltage
(max 30 V)
- -
8
8
4(8)
Application
AK-operation
AK - Com port
AK - RS 232
AK - USB
Supply for controller
To be mounted in an AK controller
Data communication for external extension modules
Analog Stepper Module with
outputs output switches
0-10 V d.c. For valves For override of
with step relay outputs
control
-
4
4
2
-
x
x
