Installation

5.
The sensor is an optical sensor for measurements with micrometer accuracy. Make sure it is handled care-
fully when installing and operating.
i
5.1
Mount the sensor only to the existing holes on a flat surface. Clamps of any kind are not permitted.
> Inaccurate, erroneous measuring values
The sensor is mounted by means of screws type M4 or M5.
For alignment try squares or rails are suitable aids.
Housing
ODC1200-...-T
ODC1200-...-R
ODC1200-90-...-T
ODC1200-90-...-R
ODC1201-...-T
ODC1201-...-R
optoCONTROL 1200/1201
Installation
Handle optical sensors with care!

Sensor Mounting

When the sensor components (light source and receiver) are mounted, initially exact alignment with
respect to one another should be ensured. Adjust the light curtain exactly to the receiver aperture.
Push through
length
mm
24
24
24
24
29
29
Bolt connection
Screw Washer
ISO 4762 - A2 ISO 7089 - A2
M4 A4.3
M4 A4.3
M4 A4.3
M4 A4.3
M4 -
M4 -
Tightening torque
per screw
µ = 0.12
Nm
2
2
2
2
2
2
