Appendix
Accessories for C-frame assembly in conjunction with adjustment plates:
BR1200L220
BR1200L320
ODC1202-L100
ODC1202-L200
ODC1202-L500
BR1200L
Bracket for
mounting as
C-frame
optoCONTROL 1200/1201
Bracket for mounting as C-frame, length 220mm, 2 pcs. required
Bracket for mounting as C-frame, length 320mm, 2 pcs. required
Mounting rail for ODC1202, 400mm; distance light source/receiver max.100mm
Mounting rail for ODC1202, 500mm; distance light source/receiver max. 200mm
Mounting rail for ODC1202, 800mm; distance light source/receiver max. 500mm
Light source
ODC1200/90
JU1200-VR
Adjustment plate
for transmitter
Mounting rail ODC1202-L, available in different lengths
Transmitter
ODC1200/90
BR1200L
Bracket for
mounting as
C-frame
JU1200-VT
Adjustment plate
for sensder
Page 57
