Note:Keep the clean-out traps open
during the cleaning.
Figure 46. Clean-out trap door
10. Clean all accumulated dirt under
the cylinders and in the side
tracks using a hoe and a water
jet if necessary.
CAUTION
D
O NOT USE THE WATER JET DIRECTLY
ON CONNECTORS OR BATTERY FUSES
11. Clean out the rest of the
Expert(t) 2000
TM
Note:Perform a visual inspection of
the hopper area, checking for
possible leaks in the hydraulic
system and wear on the
mechanical parts.
.
body.
Maintenance Manual
12. Rake with the hoe small pieces
of garbage out of the clean-out
trap.
13. Clean the area with a water jet.
14. Close the clean-out trap doors.
15. Retract the arm along the
hopper.
Emergency
Stop Button
Figure 47. Right side control station
16. Open the clean-out trap door on
each side of the hopper (see
Figure 48. "Hopper clean-out
trap door");
